6.5 Conversion Factors for Secondary
Units
The Tracer AV has the capability to mathematically
convert a weight into many different types of units
and instantly display those results with a press of the
key.
Units
Secondary units can be specified on the FORMAT
menu using the SECNDR parameter, or by using EDP
commands.
NOTES:
• Multipliers are preconfigured within the
Tracer AV . Manual entry is only necessary
when NONE is selected under UNITS. Long
tons and grain units listed in Table 6-4 cannot
be directly specified as primary or secondary
units. For these or other unlisted units of
weight, specify NONE under UNITS.
• Ensure that the secondary decimal point
position is set appropriately for the scale
capacity in the secondary units. If the
converted value requires more digits than are
available, the indicator will display an
overflow message (
• For example, if the primary units are short
tons, secondary units are pounds, and the
secondary decimal point is set to 8888.88, the
indicator will overflow if 5 tons or more are
applied to the scale. With 5 tons applied, and a
conversion factor of 2000, the secondary
unit's display needs five digits to the left of
the decimal point to display the 10000 lb
secondary units value.
36 Tracer AV Installation Manual
).
OVERFL
Primary Unit x Multiplier
grains 0.064799
0.002286
0.000143
0.000065
ounces 437.500
28.3495
0.06250
0.02835
pounds 7000.00
453.592
16.0000
0.453592
0.000500
0.000446
0.000453
short tons 2000.00
907.185
0.892857
0.907185
grams 15.4324
0.035274
0.002205
0.001000
kilograms 15432.4
35.2740
1000.00
2.20462
0.001102
0.000984
0.001000
metric tons 2204.62
1000.00
1.10231
0.984207
long tons 2240.00
1016.05
1.12000
1.01605
NOTE: Multipliers in italics are preconfigured
Table 6-4. Conversion Factors
Secondary Unit
grams
ounces
pounds
kilograms
grains
grams
pounds
kilograms
grains
grams
ounces
kilograms
short tons
long tons
metric tons
pounds
kilograms
long tons
metric tons
grains
ounces
pounds
kilograms
grains
ounces
grams
pounds
short tons
long tons
metric tons
pounds
kilograms
short tons
long tons
pounds
kilograms
short tons
metric tons
