3.2.4

Calibration Menu

See Section 4.0 on page 23 for calibration procedures.
DEFCAL CONFIG
CALIBR Menu
Parameter Choices
Level 2 submenus
WZERO —
WVAL —
WSPAN —
REZERO —
3.2.5

Serial Menu

See Section 6.3 on page 34 for information about the
DEFCAL
XXXXXXX FORMAT CALIBR
WZERO WV AL
Figure 3-7. Calibration Menu
Display and edit the zero calibration A/D count value.
DO NOT adjust this value after WSPAN has been set!
Display and edit the test weight value.
Display and edit the span calibration A/D count value.
Press Zero to remove an offset value from the zero and span calibrations.
Use this parameter only after WZERO and WSPAN have been set. See Section 4.2 on
page 24 for more information about using this parameter.
Table 3-6. Calibration Menu Parameters
CONFIG FORMAT XXXXXXX CALIBR
EDP
BAUD BITS TERMIN
9600 8NONE
CR/LF
19200
7EVEN CR
7ODD
38400
300
600
1200
2400
4800
Figure 3-8. Serial Menu
SERIAL PROGRM XXXXXXX SETPNT
WSPAN
Press Zero key to
remove offset from
zero and span
Description
Tracer AV serial data format.
SERIAL PROGRM XXXXXXX SETPNT
ECHO
EOLDLY
000
ON
number OFF
Tracer AV Installation Manual - Configuration
VERS
REZERO
calibrations
VERS
