- Page 1 WE503D Dynamic Integrator for Belt Scales, Screw Weighers, Bulkslide Flowmeters and Impact Flowmeters Program Version: v3.07 Operator Manual June 20, 2023 PN 203018 Rev B...
- Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
-
Page 3: Revision History
June 20, 2023 Established revision history; Updates to Calibration and Direct Function Codes; firmware version 3.07 Table i. Revision Letter History Technical training seminars are available through Rice Lake Weighing Systems. Course descriptions and dates can be viewed at www.ricelake.com/training or obtained by calling 715-234-9171 and asking for the training department. -
Page 4: Table Of Contents
7.0 Direct Function Codes ..............17 Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. -
Page 5: Introduction
This manual describes in short form the essential functions of the WE503D weighing terminal. For technical details on calibration and configuration please refer to WE503 Installation Manual. Ensure the WE503D Dynamic Integrator is fully installed by following the instructions of the WE503D Dynamic Integrator Installation Manual (PN 200479). -
Page 6: Technical Features
If a permanently connected power cable is used, an easily accessible separator must be included in the power supply circuit. Compliance with the following safety instruction is mandatory for UL approved units: For power supply of the WE503D use LPS and/or NEC class 2 power supply units only. -
Page 7: Display And Keyboard
Readings in the zoom window and in the bottom-lines can be selected through: • While zoom window is shown, one bottom-line, select with F7 • While standard window is shown, two bottom-lines, select with F6 or F7 © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 8: Keyboard
WE503D Dynamic Integrator Keyboard Function If pressed for 3-seconds, it will power off and restart; CLR / PWR Step back in menus, delete characters or clear an entry field Second alternative function, see function keys; ALT / SCALE Switch scale, if application allows Enter, confirm, next step in menus;... -
Page 9: Display
The FN (Enter) key was pressed to follow with a function key The ALT key was pressed to follow with a function key Keyboard locked Printer Data transmission to PC or printer is active Table 2-3. Annunciator Descriptions © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 10: Operation
WE503D Dynamic Integrator Operation Startup The WE503 is automatically turned on as soon as it is powered. The display shows: • Initially a welcome message (MASTER logo), while the instrument carries out a series of checking and self-tests • Name, version of the installed software •... -
Page 11: Help Menu
Press F1: New article, selected index or first free index. Press F2: Edit selected article. Press F3: Delete selected article. Press F4: Search article. Press F5: Print article. Press Enter: Select article. Press Alt: Unselect article. © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 12: Select Article
WE503D Dynamic Integrator 3.7.2 Select Article To Select an article from the database function in alphabetical order code 317 can be used. This function code can be used from the main screen in Operator mode or can be assigned to a function key. -
Page 13: Transport, Maintenance, Cleaning
Do not use any type of industrial solvent or the finish of the unit may be damaged. Do not spray cleaner directly on the unit. Clean the keyboard and covers with a soft clean cloth that has been dampened with a mild window type cleaner. © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 14: Service
WE503D Dynamic Integrator Service CAUTION: Only permit qualified personnel to service this equipment. Exercise care when making checks, tests, and adjustments! If any problem arises that has not been explained, verify the following: • Power supply on and line cord is undamaged (visual inspection) •... -
Page 15: Calibration
5. Enter the real dosed weight value (measured on a scale or weighbridge) and confirm with the Enter key. 6. The error and the new correction factor is displays. 7. Accept the calibration by pressing the Enter key or ignore with the CLR key. © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 16: Test Weight Calibration
WE503D Dynamic Integrator Test Weight Calibration NOTE: The correction factor affects the flow and totalizer results. The test weight calibration procedure can start by a function code or digital input (configured to MNU.FUN 328 test weight procedure). Start by function code: 1. -
Page 17: Direct Function Codes
Default Linked to Key Other Functions Link print format to print function Direct link 2nd print format to print function Setpoints values Switch 1st LCD Line (Zoom Disabled) Table 7-2. Function Codes 200-208 © Rice Lake Weighing Systems ● All Rights Reserved... - Page 18 WE503D Dynamic Integrator ID Code Function Default Linked to Key Belt Functions Dynamic belt zeroing Static zeroing Enable/disable flow-rate visualization inside dead band Run belt Set target flow-rate (PID enabled) Set target dosage weight (Batch enabled) Set pulse weight Set dosage time...
- Page 20 © Rice Lake Weighing Systems Content subject to change without notice. 230 W. Coleman St. • Rice Lake, WI 54868 • USA USA: 800-472-6703 • International: +1-715-234-9171 June 20, 2023 PN 203018 Rev B www.ricelake.com...
