AUDIO SAMPLE RATES

MASTER CLOCK AND PHASE LOCKED LOOP (PLL)

Rev 4.4

LOOPBACK

Setting the ADC_LOOPBACK or DAC_LOOPBACK register bit enables digital loopback. When the
ADC_LOOPBACK bit is set the output data from the ADC audio interface is fed directly into the DAC
data input. When the DAC_LOOPBACK bit is set the output data from the DAC audio interface is fed
directly to the input of the ADC audio interface.
The WM8940 sample rates for the ADC and the DAC are set using the SR register bits. The cutoffs
for the digital filters and the ALC attack/decay times stated are determined using these values and
assume a 256fs master clock rate.
If a sample rate that is not explicitly supported by the SR register settings is required then the closest
SR value to that sample rate should be chosen, the filter characteristics and the ALC attack, decay
and hold times will scale appropriately.
REGISTER BIT LABEL
ADDRESS
R7 3:1 SR
Additional
control
Table 45 Sample Rate Control
The WM8940 has an on-chip phase-locked loop (PLL) circuit that can be used to:
•
Generate master clocks for the WM8940 audio functions from another external clock, e.g.
in telecoms applications.
•
Generate an output clock, on pin CSB/GPIO, for another part of the system (derived from
an existing audio master clock).
Figure 30 shows the PLL and internal clocking arrangement on the WM8940.
The PLL is enabled or disabled by the PLLEN register bit.
Note: In order to minimise current consumption, the PLL is disabled when the VMIDSEL[1:0] bits are set to
00b. VMIDSEL[1:0] must be set to a value other than 00b to enable the PLL.
REGISTER BIT
ADDRESS
R1 5
Power
management 1
Table 46 PLLEN Control Bit
DEFAULT
000 Approximate sample rate (configures the
coefficients for the internal digital filters):
000=48kHz
001=32kHz
010=24kHz
011=16kHz
100=12kHz
101=8kHz
110-111=reserved
LABEL DEFAULT
PLLEN 0 PLL enable
0=PLL off
1=PLL on
WM8940
DESCRIPTION
DESCRIPTION
