CONTROL INTERFACE TIMING – 3-WIRE MODE
Test Conditions
DCVDD = 1.8V, DBVDD = AVDD = SPKVDD = 3.3V, DGND = AGND = SPKGND = 0V, T
MCLK = 256fs, 24-bit data, unless otherwise stated.
PARAMETER
Program Register Input Information
SCLK rising edge to CSB rising edge
SCLK pulse cycle time
SCLK pulse width low
SCLK pulse width high
SDIN to SCLK set-up time
SCLK to SDIN hold time
CSB pulse width low
CSB pulse width high
CSB rising to SCLK rising
Pulse width of spikes that will be suppressed
Rev 4.4
CSB/GPIO
SCLK
SDIN
Figure 4 Control Interface Timing – 3-Wire Serial Control Mode
t
CSL
t
SCY
t
t
SCH
SCL
t
t
DSU
DHO
= +25
A
SYMBOL
MIN
t
80
SCS
t
200
SCY
t
80
SCL
t
80
SCH
t
40
DSU
t
40
DHO
t
40
CSL
t
40
CSH
t
40
CSS
t
0
ps
WM8940
t
CSH
t
CSS
t
SCS
LSB
o
C, Slave Mode, fs = 48kHz,
TYP
MAX
UNIT
ns
ns
ns
ns
ns
ns
ns
ns
ns
5
ns
17
