POWER MANAGEMENT

66

VMID

The analogue circuitry will not work when VMID is disabled (VMIDSEL[1:0] = 00b). The impedance of
the VMID resistor string, together with the decoupling capacitor on the VMID pin will determine the
start-up time of the VMID circuit.
REGISTER BIT
ADDRESS
R1 1:0
Power
management 1
Table 57 VMID Impedance Control

BIASEN

REGISTER BIT
ADDRESS
R1 3
Power
management 1
Table 58 BIASEN Control

ESTIMATED SUPPLY CURRENTS

When either the DAC or ADC are enabled it is estimated that approximately 4mA will be drawn from
DCVDD when fs=48kHz (This will be lower at lower sample rates). When the PLL is enabled an
additional 700 microamps will be drawn from DCVDD.
Table 59 shows the estimated 3.3V AVDD current drawn by various circuits, by register bit.
REGISTER BIT
MONOEN 0.2mA
PLLEN 1.4mA (with clocks applied)
MICBEN 0.5mA
BIASEN 0.3mA
BUFIOEN 0.1mA
VMIDSEL 10K=>0.3mA, less than 0.1mA for 100k/500k
BOOSTEN 0.2mA
INPPGAEN 0.2mA
ADCEN 2.6mA
MONOEN 0.2mA
SPKPEN 1mA from SPKVDD
SPKNEN 1mA from SPKVDD
MONOMIXEN 0.2mA
SPKMIXEN 0.2mA
DACEN 1.8mA
Table 59 AVDD Supply Current
LABEL DEFAULT
VMIDSEL 00 Reference string impedance to VMID pin
(determines startup time):
00=off (open circuit)
01=50kΩ
10=250kΩ
11=5kΩ (for fastest startup)
LABEL DEFAULT
BIASEN 0 Analogue amplifier bias control
0=Disabled
1=Enabled
AVDD CURRENT (MILLIAMPS)
WM8940
DESCRIPTION
DESCRIPTION
Rev 4.4
