REGISTER
BIT
LABEL
ADDRESS
0
5 (05h)
15:7
6
DAC_LOOPBA
CK
5
WL8
4:3
DAC_COMP
2:1
ADC_COMP
0
ADC_LOOPBA
CK
6 (06h)
15:9
8
CLKSEL
7:5
MCLKDIV
4:2
BCLKDIV
1
0
MS
7 (07h)
15:7
Rev 4.4
DEFAULT
0
Reserved
0000
Reserved
0
Digital loopback function
0=No DAC loopback
1=Loopback enabled, DAC data input is fed directly
into ADC data output.
0
8 Bit Word Length for companding
0=Word Length controlled by WL
1=8 bits
00
DAC companding
00=off
01=reserved
10=µ-law
11=A-law
00
ADC companding
00=off
01=reserved
10=µ-law
11=A-law
0
Digital loopback function
0=No ADC loopback
1=Loopback enabled, ADC data output is fed directly
into DAC data input.
00h
Reserved
1
Controls the source of the clock for all internal
operation:
0=MCLK
1=PLL output
010
Sets the scaling for either the MCLK or PLL clock
output (under control of CLKSEL)
000=divide by 1
001=divide by 1.5
010=divide by 2
011=divide by 3
100=divide by 4
101=divide by 6
110=divide by 8
111=divide by 12
000
Configures the BCLK and FRAME output frequency,
for use when the chip is master over BCLK.
000=divide by 1 (BCLK=MCLK)
001=divide by 2 (BCLK=MCLK/2)
010=divide by 4
011=divide by 8
100=divide by 16
101=divide by 32
110=reserved
111=reserved
0
Reserved
0
Sets the chip to be master over FRAME and BCLK
0=BCLK and FRAME clock are inputs
1=BCLK and FRAME clock are outputs generated by
the WM8940 (MASTER)
00000
Reserved
DESCRIPTION
WM8940
REFER TO
Digital Audio
Interfaces
Digital Audio
Interfaces
Digital Audio
Interfaces
Digital Audio
Interfaces
Digital Audio
Interfaces
Digital Audio
Interfaces
Digital Audio
Interfaces
Digital Audio
Interfaces
Digital Audio
Interfaces
71
