1.2. VCI BOX

LCD: Display the battery voltage of the vehicle
1
OBD 16 pin connector: Insert the OBD-Ⅱ port on the vehicle
2
Light button: provide lighting function
3
Bluetooth Indicator: It turns blue when Bluetooth is connected
4
successfully
Power Indicator: It turns red when power is on
5
Vehicle Indicator: The green light flashes when the VCI box
6
communicates with the vehicle successfully
Fig 1-4 Sample of VCI Box
