Operating Supplies, Specifications - Presto CONTI COMPACT CC-20 V Operating Manual

Maintenance
7.5. Operating supplies,
specifications
Factory filling:
Esso HLP 32
Comparable grades of oil:
ARAL GF 32
Spray grease for other lubricating points
Use commercial chain spray grease.
Tie wire for all CCs:
auf 20 kg, 40 kg‐bzw. 250 kg Rolle
patentgespult,
on 40 kg‐ respectively 250 kg reels,
patent wound, and diameter 2,8
to 3,4 mm soft‐annealed and
oiled, quality 9‐1, according DIN
EN 10218‐2.
Basically, the wire gauge must be adapted
to the material properties.
Do not use old, corroded wires!
7.5.1. Quantities of operating supplies
See hydraulic circuit plan
04/2015 S. 67
Observe safety conditions!
SWITCHING OFF & SECURE
(see 7.1)
