Presto CONTI COMPACT CC-20 V Operating Manual page 35

Constructive description
30 °C, an oil cooler may have to be
installed. (see fig. 45).
Fig. 46: oil cooler
Machines which are sited in rooms with a
constant temperature of less than 10 °C
must be provided with an add‐on heater.
The heating element with 1000W and an
integrated thermostat keeps the oil at an
operational temperature of at least 17°C.
For this, however, the main switch must
be on. Thus, if the machine is cut off from
the mains over a longer period.
Fig. 47: oil cooler
If necessary, and if not already fitted, get
in touch with our sales department or our
customer service.
04/2015 S. 35
