Presto CONTI COMPACT CC-20 V Operating Manual page 37

Constructive description
Fig. 50: emergency‐stop push‐button
Caution!
The operator or their
staff is prohibited from
interfering with the
program control.
Fig. 51: : emergency‐stop‐button at the end of
the press channel
Due to local circumstances or design
features further Emergency‐Stop switches
can be fitted to the machine.
Fig. 52: electrical motor
Fig. 53: light barrier press
Fig. 54: safety switch knotting hood
Fig. 55: proximity switch end position press (in
front)
04/2015 S. 37
