Operating controls and operation
6.5 Operating the machine
The plant may be operated in two
operating modes:
Manual "Manual"
Operating mode for work in connection
with adjusting, maintenance and repairs,
fault clearances.
Automatic "Auto"
Operating mode for standard compacting
operation. Adjustable values make sure
that the bales are compacted according to
your requirements.
Working with / at the machine
may only be carried out by
instructed persons and / or
skilled stuff.
Caution!
Danger of crushing! Never
climb into the funnel whilst
the channel baling press is
operating.
6.5.1 Works before start pressing:
• Check that the reels contain sufficient
tie wire.
These machine types are equipped
with threefold or quadruple tying‐
up devices. Six or eight coils of tying wire
are required for each of them.
• Check if all Emergency stop push‐
button switches are pulled out.
• Check if any pull cord switches that
exist are released.
• Check that all safety devices are
released and inspection flaps are
closed correctly.
• Set master switch to position "I".
• Wahlschalter Steuerung 0‐1 auf
Position „1" setzen.
• Set operating mode selector 0‐1 to
position "1".
• Press button "operation".
Lighting‐up of the integrated control
lamp indicates ready for operation of
the machine.
• Throw material into the funnel. Fill the
funnel until just above the counter
knife. The machine will start
automatically as they are all equipped
with a light barrier.
If the control lamp does not light
up, go through the points again starting at
"Check, that Emergency Stop...".
Further operation steps:
04/2015 S. 43
An individual program
description of your
machine could be find in
the annex.
