Compatibility; Compatibility For 4098 Detectors And Detector Bases - Simplex 4098 Applications Manual

Compatibility

Compatibility for
This section describes the compatibility between FACPs, detectors, and detector bases.
4098 Detectors and
Detector Bases
Notes:
1.
2.
3.
4.
5.
Table 5-1. 4098 Detector and Detector Base Compatibility
Compatible 2-
Detectors Wire Detector
Base
4098-9601 4098-9788
4098-9602 4098-9684
4098-9603 (LED base for
4098-9605 Heat Detectors
4098-9612 Only)
4098-9613
4098-9614
4098-9615
4098-9683
Relay operation cannot be guaranteed unless it is the only device on that zone.
Panel compatibility identification marker is model number of the module or panel.
Detector compatibility identification marker is model number found on detector label.
For detailed interconnection data, see wiring diagrams for specific panels.
For additional compatibility listings see 579-832 for 2-wire detector compatibility charts.
firealarmresources.com
System
2120 ET/FADM
2120 FABT/VPBT
2120/4100+ ZAM
4001
4002
4020
4100ES/4100U/4100+/4120/UT
4004/4005
4006
4004/4005 High Current
(Relay base not used with
4004 and 4005 Low Current
systems)
5-2
Max. Quantity
of Bases per
Initiating
Circuit
25
18
20
18
30
30
30
20
30
30
1
(See Note 1)
Continued on next page
