Relay Module Installation; Remote Led Module - Simplex 4098 Applications Manual

Relay Module Accessories,
Relay Module
Install the relay module using the following steps:
Installation
1. Mount a 1-1/2 inch (3.81 cm) extension ring (not supplied) to an octagonal or square
2. Mount relay module inside extension ring directly behind base and sensor. Do not mount
Note: Use the exact configuration of electrical box (square or octagonal) with extension to

Remote LED Module

The 2098-9808 Remote LED Module is available for the 4098-9789 ,-9791, -9794, -9795, -9796
Sensor Bases.
Use the figure below as a reference when installing the Remote LED Module to a sensor base.
To 4098-9789, -9791, -9794, -9795, -9796 Sensor Base
Continued
electrical box (not supplied). The extension ring is required to meet the minimum box
volume requirement (32.3 cu. inch/529.4 cu. cm) for relay module installation.
remotely. See Figure 4-1 or 4-2 for relay module connections.
mount sensor base when installing the relay module.
Figure 4-3. 2098-9808 Remote LED Module Wiring
firealarmresources.com
RED BLACK
2098-9808
LED
4-4
