Simplex 4098 Applications Manual page 36

4098 TrueAlarm Sensor Bases,
Address Setting for
The figure below shows the address DIP Switch settings for the 4010, 4008, 4020, 4100+, 4100U,
the 4010, 4020,
4100ES and 4120 Systems. Refer to the "Compatibility and Testing" chapter of this publication
4100+, 4100U,
for information on which devices are compatible with the various FACPs.
4100ES, 4008, or
4120 System
Note: The 4020, 4100+, 4100U, 4100ES, 4008, and 4120 systems support up to 127 devices on
FigureTag FD4-709-08
LSB
1 2 3 4
ON
OFF
0000 1000 0100 1100 0010 1010 0110 1110 0001 1001 0101 1101 0011 1011 0111 1111
0000
1000
0100
1100
0010
1010
0110
1110
0001
1001
0101
1101
0011
1011
0111
1111
Figure 3-5. 4010, 4020, 4100+, 4100U, 4100ES, 4008, or 4120 MAPNET/IDNet Addresses
Continued
each of their MAPNET II channels. The 4010 supports up to 250 devices on its IDNet
channel.
MSB DIPSWITCH IS SHOWN SET AT ADDRESS 7.
5 6 7 8
1 = ON
0 16 32 48 64
1 17 33 49 65
2 18 34 50 66
3 19 35 51 67
4 20 36 52 68
5 21 37 53 69
6 22 38 54 70
7 23 39 55 71
8 24 40 56 72
9 25 41 57 73
10 26 42 58 74
11 27 43 59 75
12 28 44 60 76
13 29 45 61 77
14 30 46 62 78
15 31 47 63 79
firealarmresources.com
0 = OFF
DIP SWITCHES 5 THRU 8
80 96 112 128 144 160 176 192 208 224 240
81 97 113 129 145 161 177 193 209 225 241
82 98 114 130 146 162 178 194 210 226 242
83 99 115 131 147 163 179 195 211 227 243
84 100 116 132 148 164 180 196 212 228 244
85 101 117 133 149 165 181 197 213 229 245
86 102 118 134 150 166 182 198 214 230 246
87 103 119 135 151 167 183 199 215 231 247
88 104 120 136 152 168 184 200 216 232 248
89 105 121 137 153 169 185 201 217 233 249
90 106 122 138 154 170 186 202 218 234 250
91 107 123 139 155 171 187 203 219 235
92 108 124 140 156 172 188 204 220 236
93 109 125 141 157 173 189 205 221 237
94 110 126 142 158 174 190 206 222 238
95 111 127 143 159 175 191 207 223 239
3-6
251
252
253
254
255
