Simplex 4098 Applications Manual page 28

4098 Bases,
Continued
Wiring
FigureTag FD4-709-05
INITIATING
CIRCUIT
4001, 4002
4020, 4100+, 4100U,
4100ES, 4004, 4005 OR
Figure 2-4. 4098-9683 2-Wire Relay Base Connections for Style B or D Initiating Circuits
Notes:
1. If used, 4098-9830 remote LED is polarized; refer to Figure 2-6 to wire remote LED to a heat
2. Wire only one relay base per initiating circuit.
3. For Style D initiating circuit, wire per dotted lines and do not use EOL resistor. If Style B
4. It is recommended that the Primary-1 and the Backup-2 lines be in separate wire runs and in
5. Aux. Relay contacts, each rated 1 amp at 28 VDC/0.5 amp at 125 VAC, resistive.
BACKUP 2
SEE NOTE 4
-
+
PRIMARY 1
SEE NOTE 4
+
-
LISTED
SIMPLEX
FIRE ALARM
CONTROL
PANEL
2120,
4006
detector, observe color-coded wiring.
initiating circuit, refer to wiring diagrams provided with the system panel for proper EOL
resistor value.
compliance with local requirements.
firealarmresources.com
SEE NOTE 3
NOTE
RED
BLK RED BLK
BLK
REMOTE LED
4098-9830
(SEE NOTE 1) (SEE NOTE 2)
2-12
SEE
3
EOL
RESISTOR
(IF USED)
VIO
N/C
BLU
C
GRY
N/O
(SEE NOTE 5)
YEL
N/C
ORN
C
GRN
N/O
Continued on next page
