Address Setting For The 2120 Cdt System - Simplex 4098 Applications Manual

4098 TrueAlarm Sensor Bases,
Address Setting for
1. Using the 2120 Job Configuration Report, find the entry for the sensor base (4098-9792 and
the 2120 CDT
System
2. Using the switch setting data for the base you are installing, set the base's address.
3. Double-check the location of the sensor base and its address before proceeding to electrical
Address Setting for
1. Using the Programmer's Report for the 4020 (Figure 3-3), 4100+, 4100U, 4100ES, 4120,
the 4010, 4020,
4100+, 4100U,
4100ES, 4008, or
4120 System
2. Using the example given in Step 1 as guideline, set the base's address using the information in
3. Mark an address label with the appropriate address for your base by shading a label box for
4. Double-check the location of the sensor base and its address before proceeding to electrical
Device
Address
Device
Address
Continued
4098-9789 only) you are about to install. The CUSTOM LABEL column provides the
location while the DEVICE ADDRESS column provides the switch setting data.
See Figure 3-1 for location of switches. Use a small screwdriver or pen to set the switches.
installation (see Figure 2-1).
4008, or 4010 (Figure 3-4), find the entry for the sensor base you are about to install. The
device ADDRESS and CUSTOM LABEL are located in the SYSTEM POINT SUMMARY
under "M."For example, Address M1-7 (for the 4100+, 4100U, 4100ES, 4120, 4008, or 4010
system) is circled in Figure 3-4. M1 is the addressable channel while -7 is the device address
on the channel. For a base with Address M1-7, Address 7 must be set on the base's DIP
Switches (SW1).
Figure 3-5. See Figure 3-1 and 3-2 for location of DIP Switches. Use a small screwdriver or
pen to set the switches.
each base DIP Switch in the ON position. Then apply the label to the base near the base's
DIP Switch.
installation.
Figure 3-3. 4020 Programmer's Report
Figure 3-4. 4100+, 4100U, 4100ES, 4120, 4008, or 4010 Programmer's Report
firealarmresources.com
3-5
