Levelflex FMP53 FOUNDATION Fieldbus
Value 1 to 4 display
Navigation
Description
Selection
Factory setting
Decimal places 1 to 4
Navigation
Description
40) can not be selected for the ' V alue 1 display" parameter.
41) "Visibility depends on order options or device settings"
Endress+Hauser
 38 "Format display" = "4 values"
• The Value 1 to 4 display →  169 parameters specify which measured values are
shown on the display and in which order.
• If more measured values are specified than the current display mode permits, the
values alternate on the device display. The display time until the next change is
configured in the Display interval parameter (→  170).
 Setup → Advanced setup → Display → Value 1 display
Select the measured value that is shown on the local display.
40)
• None
• Level linearized
• Distance
41)
• Current output 1
• Measured current
• Current output 2
• Terminal voltage
• Electronic temperature
• Analog output adv. diagnostics 1
• Analog output adv. diagnostics 2
For level measurements
• Value 1 display: Level linearized
• Value 2 display: Distance
• Value 3 display: Current output 1
• Value 4 display: None
 Setup → Advanced setup → Display → Decimal places 1
Select the number of decimal places for the display value.
Â
93.5 %
1
Â
159.0 mm
1
Â
93.5 V
V 1
Â
26.3 °C
1
Operating menu
A0019968


169
