Endress+Hauser Levelflex FMP53 FOUNDATION Fieldbus Operating Instructions Manual page 151

Levelflex FMP53 FOUNDATION Fieldbus
Maximum value
Navigation
Prerequsite
Description
User entry
Factory setting
Diameter
Navigation
Prerequsite
Description
User entry
Factory setting
Additional information
Intermediate height
Navigation
Prerequsite
Description
User entry
Factory setting
Endress+Hauser
 Setup → Advanced setup → Linearization → Maximum value
Linearization type (→  148) has one of the following values:
• Linear
• Pyramid bottom
• Conical bottom
• Angled bottom
• Horizontal cylinder
• Sphere
Specify the maximum content of the vessel (100%) measured in the units after
linearization.
–50 000.0 to 50 000.0 %
100.0 %
 Setup → Advanced setup → Linearization → Diameter
Linearization type (→  148) has one of the following values:
• Horizontal cylinder
• Sphere
Specify tank diameter.
0 to 9 999.999 m
2 m
The unit is defined in the Distance unit parameter (→  128).
 Setup → Advanced setup → Linearization → Intermed. height
Linearization type (→  148) has one of the following values:
• Pyramid bottom
• Conical bottom
• Angled bottom
Specify intermediate height H.
0 to 200 m
0 m
Operating menu



151
