Mounting
24
Divisible probes
If there is little mounting space (distance to the ceiling), it is advisable to use divisible rod
probes ( 8 mm).
• max. probe length 6 m/236 inch
• max. sideways capacity 10 Nm
• probes are separable several times with the following lengths of the individual parts:
– 500 mm (20 in)
– 1 000 mm (40 in)
• torque: 4.5 Nm
• The joints are sealed seamlessly with an O-ring.
In order to avoid damages of the probe surface: Use plumber wrenches with plastic
surface to mount the probe rod.
Levelflex FMP53 FOUNDATION Fieldbus
SW10
AF10
Endress+Hauser
A0014166
