Levelflex FMP53 FOUNDATION Fieldbus
Endress+Hauser
3. Pull out the display module with a gentle rotation movement. To make it easier to
access the SIM switch, attach the display module to the edge of the electronics
compartment.
Display module is attached to the edge of the electronics compartment.
4. SIM switch in the ON position: measured values can be simulated. SIM switch in the
OFF position (factory setting): Simulation of measured values is disabled.
5. Feed the spiral cable into the gap between the housing and main electronics module
and plug the display module into the electronics compartment in the desired
direction until it engages.
6. Screw the electronics compartment cover closed and tighten the securing clamp.
Operating menu
A0013909
193
