Operating menu
Logging interval
Navigation
Description
User entry
Factory setting
Additional information
Clear logging data
Navigation
Description
Selection
Factory setting
190
 Diagnostics → Data logging → Logging interval
Define logging interval t
log
1.0 to 3 600.0 s
30.0 s
This parameter defines the interval between the individual data points in the data log, and
thus the maximum loggable process time T
• If 1 logging channel is used: T
• If 2 logging channels are used: T
• If 3 logging channels are used: T
• If 4 logging channels are used: T
Once this time elapses, the oldest data points in the data log are cyclically overwritten such
that a time of T always remains in the memory (ring memory principle).
log
The logged data are deleted if this parameter is changed.
Example
When using 1 logging channel
• T = 500 ⋅ 1 s = 500 s ≈ 8.5 min
log
• T = 500 ⋅ 10 s = 5 000 s ≈ 1.5 h
log
• T = 500 ⋅ 80 s = 40 000 s ≈ 11 h
log
• T = 500 ⋅ 3 600 s = 1 800 000 s ≈ 20 d
log
 Diagnostics → Data logging → Clear logging
Initiate a deletion of the complete logging memory.
• Cancel
• Clear data
Cancel
Levelflex FMP53 FOUNDATION Fieldbus
.
:
log
= 500 ⋅ t
log log
= 250 ⋅ t
log log
= 166 ⋅ t
log log
= 125 ⋅ t
log log


