Setup" Menu - Endress+Hauser Levelflex FMP53 FOUNDATION Fieldbus Operating Instructions Manual

Operating menu
Distance unit
Navigation
Description
Selection
Factory setting
Tank type
Navigation
Prerequsite
Description
Selection
Factory setting
Additional information
128
17.3

"Setup" menu

• : Marks the navigation path to the parameter via the display and operating
module.
• : Marks the navigation path to the parameter via an operating tool (e.g.
FieldCare).
• : Marks parameters which can be locked via the software locking →  48.
Navigation  Setup
 Setup → Distance unit
Select distance unit.
SI units
• mm
• m
m
 Setup → Tank type
Medium type (→  140) = Liquid
Select tank type.
• Metallic
• Bypass / pipe
• Non metallic
• Mounted outside
• Coaxial
Depending on the probe
• Depending on the probe some of the options mentioned above may not be available or
there may be additional options.
• For probes with metallic center washer, Tank type = Bypass / pipe is preset and can not
be changed.
Levelflex FMP53 FOUNDATION Fieldbus
US units
• ft
• in


Endress+Hauser
