Brief Operating Instructions
Levelflex FMP51, FMP52,
FMP54
FOUNDATION Fieldbus
Guided wave radar
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
Available for all device versions via:
• Internet:
www.endress.com/deviceviewer
• Smart phone/tablet: Endress+Hauser Operations App
Solutions
Services
Advertisement
Table of Contents
Related Manuals for Endress+Hauser FOUNDATION Fieldbus Levelflex FMP51
Summary of Contents for Endress+Hauser FOUNDATION Fieldbus Levelflex FMP51
- Page 1 Operating Instructions pertaining to the device. Detailed information about the device can be found in the Operating Instructions and the other documentation: Available for all device versions via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App...
-
Page 2: Associated Documentation
Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 About this document Symbols 2.1.1 Safety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. - Page 3 Symbols for certain types of information and graphics Permitted Procedures, processes or actions that are permitted Forbidden Procedures, processes or actions that are forbidden Tip Indicates additional information Reference to documentation Reference to graphic Notice or individual step to be observed Endress+Hauser...
-
Page 4: Basic Safety Instructions
‣ Measured process variables: level and/or interface height ‣ Calculable process variables: volume or mass in any shape of vessel (calculated from the level by the linearization functionality) Endress+Hauser... -
Page 5: Workplace Safety
The manufacturer is not liable for damage caused by improper or non-intended use. Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability. -
Page 6: Product Safety
• Are the goods undamaged? • Do the nameplate data match the ordering information on the delivery note? • If required (see nameplate): are the Safety Instructions (XA) provided? If one of these conditions is not met, please contact your Endress+Hauser sales office. Endress+Hauser... -
Page 7: Product Identification
‣ Enter the serial number from the nameplate in the Endress+Hauser Operations app or scan the 2-D matrix code on the nameplate with the camera All of the information on the measuring device and on the scope of the technical documentation pertaining to the device is displayed. - Page 8 Incoming acceptance and product identification Levelflex FMP51, FMP52, FMP54 FOUNDATION Fieldbus A0013920 Endress+Hauser...
-
Page 9: Mounting Requirements
Levelflex FMP51, FMP52, FMP54 FOUNDATION Fieldbus Mounting Mounting Mounting requirements 5.1.1 Suitable mounting position A0012606 1 Installation conditions for Levelflex Endress+Hauser... - Page 10 Securing the probe Securing rope probes A0012609 Rope sag: ≥ 10 mm/(1 m probe length) [0.12 in/(1 ft probe length)] Reliably grounded end of probe Reliably insulated end of probe Fastener in female thread of probe end weight Insulated fastening kit Endress+Hauser...
- Page 11 • In the case of WHG approval: a support is required for probe lengths ≥ 3 m (10 ft). • In general, rod probes must be secured in the event of horizontal flow (e.g. from an agitator) or strong vibrations. • Only secure rod probes directly at the end of the probe. Endress+Hauser...
- Page 12 Probe Ø 8 mm (0.31 in) • a < Ø 14 mm (0.55 in) • b = Ø 8.5 mm (0.34 in) Probe Ø 12 mm (0.47 in) • a < Ø 20 mm (0.78 in) • b = Ø 12.5 mm (0.52 in) Endress+Hauser...
- Page 13 Securing coax probes For WHG approval: a support is required for probe lengths ≥ 3 m (10 ft). A0012608 Coax probes can be secured (fixed) at any point in the ground tube. 5.1.3 Shortening the probe See Operating Instructions. Endress+Hauser...
-
Page 14: Mounting The Device
If a seal is used to mount the device, use uncoated metal screws to ensure good electrical contact between the process flange and the probe flange. 5.2.3 Mounting rope probes NOTICE Electrostatic discharge can damage the electronics. ‣ Ground the housing before lowering the rope probe into the vessel. Endress+Hauser... - Page 15 350° 8 mm 8 mm A0032242 Unscrew the securing screw using an open-ended wrench. Rotate the housing in the desired direction. Tighten the securing screw (1.5 Nm for plastic housing; 2.5 Nm for aluminum or stainless steel housing). Endress+Hauser...
- Page 16 Turn the display module to the desired position: Max. 8 × 45 ° in each direction. Feed the coiled cable into the gap between the housing and main electronics module and plug the display module into the electronics compartment until it engages. Endress+Hauser...
-
Page 17: Electrical Connection
Turn the securing clamp 90 ° in the clockwise direction and, using an Allen key (3 mm), tighten the screw of the securing clamp on the electronics compartment cover with 2.5 Nm. Electrical connection Connecting requirements 6.1.1 Terminal assignment Endress+Hauser... - Page 18 Cable screen; observe cable specification Connection PROFIBUS PA / FOUNDATION Fieldbus Measuring device Switch output (open collector) 6.1.2 Device plug In the case of the device versions with a plug, the housing does not need to be opened to connect the signal cable. Endress+Hauser...
- Page 19 • Ex ia + Ex d[ia] / IS + XP Feature 020 in the product structure Feature 010 in the product structure Input voltages up to 35 V do not destroy the device. Polarity-dependent FISCO/FNICO compliant according to IEC 60079-27 6.1.4 Overvoltage protection See Operating Instructions. Endress+Hauser...
-
Page 20: Connecting The Device
Loosen the screw of the securing clamp of the connection compartment cover using an Allen key (3 mm) and turn the clamp 90 ° counterclockwise. Unscrew the connection compartment cover and check the cover seal; replace it if necessary. 6.2.2 Connecting A0036418 5 Engineering unit: mm (in) Endress+Hauser... - Page 21 6 Engineering unit: mm (in) To remove the cable from the terminal again: Using a flat-blade screwdriver ≤ 3 mm, press down on the slot between the two terminal holes Simultaneously pull the cable end out of the terminal. Endress+Hauser...
-
Page 22: Operation Options
2.5 Nm. Operation options The device can be operated as follows: • Operation via operating menu (display) • DeviceCare and Fieldcare, see Operating Instructions • SmartBlue (app), Bluetooth (optional) see Operating Instructions Endress+Hauser... -
Page 23: Structure And Function Of The Operating Menu
Visualization of a parameter (here: parameter with picklist) 3.1 Header containing parameter name and error symbol (if an error is active) 3.2 Picklist; marks the current parameter value. Input matrix for numbers Input matrix for alphanumeric and special characters Endress+Hauser... - Page 24 • If present, opens the help text for the function of the parameter. • In a text and numeric editor: Pressing the key briefly: • Opens the selected group. • Carries out the selected action. • Carries out the selected action. Endress+Hauser...
-
Page 25: Access To The Operating Menu Via The Local Display
When you call up the "Expert" menu, you are always asked for an access code. If a customer-specific access code has not been defined, "0000" must be entered. 7.2.1 Opening the context menu Using the context menu, the user can call up the following menus quickly and directly from the operational display: Endress+Hauser... -
Page 26: Switching On The Device
Disabling write protection If the device is write-protected, write protection must first be disabled. See the Operating Instructions of the device for this purpose: BA01052F (FMP51/FMP52/FMP54, FOUNDATION Fieldbus) Setting the operating language Factory setting: English or ordered local language Endress+Hauser... - Page 27 Main menu 0104-1 Display language English Operation Setup Display language 0104-1 English à Deutsch Español Français Display language 0104-1 à English Deutsch Español Français Hauptmenü 0104-1 Sprache Deutsch Betrieb Setup A0029420 9 Taking the example of the local display Endress+Hauser...
-
Page 28: Device Configuration
Select Level option. Setup → Tank type Select tank type. Setup → Tube diameter (only for "Tank type" = "Bypass / pipe") Specify the diameter of the bypass or stilling well. Only available in devices with the "Interface measurement" application package Endress+Hauser... - Page 29 Compare the distance displayed with the actual value in order to start recording an interference echo map In the case of FMP54 with gas phase compensation (product structure: feature 540 "Application packages", option EF or EG), mapping cannot be performed Endress+Hauser...
- Page 30 Enter device tag. Setup → Distance unit Select the length unit. Setup → Operating mode Select Interface option. Setup → Tank type Select tank type. Only available in devices with the "Interface measurement" application package Endress+Hauser...
- Page 31 R and the interface L 15. Setup → Signal quality Displays the signal quality of the analyzed level echo. 16. Setup → Mapping → Confirm distance Compare the distance displayed with the actual value to start recording an interference echo map. Endress+Hauser...
- Page 32 *71565976* 71565976 www.addresses.endress.com...
