EAS30657

CHANGING THE ENGINE OIL

1. Start the engine, warm it up for several min-
utes, and then turn it off.
2. Place a container under the engine oil drain
bolt.
3. Remove:
• Engine oil filler cap "1"
(along with the O-ring "2")
• Engine oil drain bolt "3"
(along with the gasket "4")
1
2
4. Drain:
• Engine oil
(completely from the crankcase)
5. If the oil strainer is also to be cleaned, per-
form the following procedure.
a. Remove the oil filter element cover "1" and
oil filter element "2".
b. Install a new O-ring "3"
TIP
Lubricate the O-ring with lithium-soap-based
grease.
1
4 3
.
New
2
LS
3 New
3-19
PERIODIC MAINTENANCE
c. Install the oil filter element and oil filter el-
ement cover.
Oil filter element cover bolt
10 N·m (1.0 kgf·m, 7.4 lb·ft)
6. Install:
• Engine oil drain bolt
(along with the gasket
Engine oil drain bolt
20 N·m (2.0 kgf·m, 15 lb·ft)
7. Fill:
• Crankcase
(with the specified amount of the recom-
mended engine oil)
Engine oil quantity
Oil change
1.50 L (1.59 US qt, 1.32 Imp.qt)
With oil filter removal
1.60 L (1.69 US qt, 1.41 Imp.qt)
Quantity (disassembled)
1.70 L (1.80 US qt, 1.50 Imp.qt)
8. Install:
• Engine oil filler cap
(along with the O-ring
9. Start the engine, warm it up for several min-
utes, and then turn it off.
10.Check:
• Engine
(for engine oil leaks)
11.Check:
• Engine oil level
Refer to "CHECKING THE ENGINE OIL
LEVEL" on page 3-18.
12.Remove:
• Storage box
Refer to "GENERAL CHASSIS (4)" on page
4-10.
13.Check:
• Engine oil pressure
a. Slightly loosen the oil check bolt "1".
1
)
New
)
New
