PICO512 Pico-ITX Board
2.5.2

SATA Connector (CN4)

This Serial Advanced Technology Attachment (Serial ATA or SATA) connector is for
high-speed SATA interface port. It is a computer bus interface for connecting to devices
such as hard disk drive.
Pin
1
2
3
4
5
6
7
2.5.3

CMOS Battery Connector (CN5)

This connector is for CMOS battery interface.
Pin
1
2
2.5.4

Fan Power Connector (CN6)

The CN6 is a 2-pin (pitch=1.5mm) wafer connector for fan power interface.
Pin
1
2
2.5.5

Digital I/O Connector (CN7)

This is a 5x2-pin (pitch=2.0mm) pin header. The board is equipped with an 8-channel (3
inputs and 5 outputs) digital I/O that meets requirements for a system customary
automation control. The digital I/O can be configured to control cash drawers and sense
warning signals from an Uninterrupted Power System (UPS), or perform store security
control. You may use software programming to control these digital signals, see
Appendix B.
Pin
Signal
1
DIO0
3
DIO1
5
DIO2
7
DIO3
9
+5V
16
Signal
GND
TXP
TXN
GND
RXN
RXP
GND
Signal
+3.3V
GND
Signal
+5V
GND
Pin
Signal
2
DIO4
4
DIO5
6
DIO6
8
DIO7
10
GND
7
1
1
1
Board and Pin Assignments
