PICO512 Pico-ITX Board
Use the following four screws to secure heatsink on heatspreader.
3.
The PICO512 has four assembly holes for installing thermal solution. Align and firmly
4.
secure the plate to the PICO512. Be careful not to over-tighten the screws.
x4
10
x2
x2
x4
x4
