Dvb-S/S2 Mod. Card - Sumavision EMR3.0 Operating Instructions Manual

Parameter
Switch
Output Frequency
(MHz)
Transfer Mode
Guard Interval
Modulation
Interleave Depth
Hierarchical Mode
Inner Code
Bitrate(HP/LP)
Bitrate Adaption
DVB-H Signaling
Cell ID Enabled
Cell ID
T.S. (HP/LP)
MPE (HP/LP)

5.3.9 DVB-S/S2 Mod. Card

5.3.9.1 Interface
DVB-S/S2 Mod. Card bases on EMR3.0 platform to provide functions of
single-channel ASI input and single-channel RF output. It is used to modulate the program
stream to the RF signal of DVB-S/S2 standard, as shown in Fig. 5-63 DVB-S/S2 Mod. Card:
5.3.9.2 Function
DVB-S/S2 Mod. Card bases on EMR3.0 platform to support 1-channel ASI input (no
Multiplexing) and 1-channel RF modulated output. Its functions include: when "Backboard
Muxing TS" is chosen, it may choose the input stream of other cards for modulated output
and when "Local ASI TS" is chosen, it realizes the modulated output of the ASI input
stream of the current card according to DVB-S/S2 modulation standard to output the
frequency signal. For the program multiplex method, refer to section 5.1.1.2Multiplexing
Setting. Parameter setting page of WEB network management is as follows:
«ТВБизнес» - официальный дистрибьютор
Table 5-22 DVB-T/H-4 Mod. Card RF Out Parameter
(1/4)/ (1/8)/ (1/16)/ (1/32)
QPSK/16QAM/64QAM
(1/4)/ (1/8)/ (1/16)/ (1/32)
No/Alpha1/Alpha2/Alpha3
(1/2)/ (2/3)/ (3/4)/ (5/6) / (7/8)
Fig. 5-63 DVB-S/S2 Mod. Card
Range
On/Off
42~870
2k/4k/8k
On/Off
On/Off
Enable/Disable
0~65535
On/Off
On/Off
+7-812-600-25-77
Default
On
500
2k
(1/32)
QPSK
(1/32)
No
(1/2)
On
Off
Disable
0
Off
Off
TVBS.RU 91
