5.3.19.2 Function
5.3.19.2.1 Receiving Parameter
1
Fig. 5-99 DVB-S2 Demod Desc Card Receiving Parameter Config
Step 1: Click "RF" of "DVB-S2 Demod Desc Card" of WEB network management to
navigate to port page;
Step 2: Click "Config" to navigate to setting page;
Step 3:Set the "Tuner" as "On" and choose the "Standard" , "TS Change" , "22KHz" ,
"Polarize" and "DiSEqC" according to the satellite programme to be received, and fill in the
"Downlink Frequency", "Local Frequency", "Symbol Rate" and "Appointed PID";
Step 4: After setting the parameter, click "Apply" to validate the parameter;
If the parameter modification cause that the satellite signal cannot be locked, it can
use the "Search" function to search the locking signal.
The monitoring interface shall display the code rate information which is currently
received.
