Connectors - AXIOMTEK SBC86840 Series User Manual

2.4
Connectors connect the board with other parts of the system. Loose or
improper connection might cause problems. Make sure all connectors
are properly and firmly connected. Here is a summary table shows you
all connectors on the SBC86840 Series.
Parallel Port or Floppy Connector (Default : LPT)
Serial Port2 Connector
Serial Port3 Connector
Serial Port4 Connector
Digital I/O (DIO) Connector
PS2 Keyboard/Mouse Connector
VGA & Serial Port1 Connector
LAN1/LAN2 Connector
USB Port1/2 & IEEE1394 Port1 Connector
LVDS Connector
TV-OUT Connector (Optional)
LVDS Backlight Connector
USB Port3/4 & IEEE1394 Port2 Connector
Serial ATA Port 2 Connector
Audio Phone Jack Connector
USB Port5/6 Connector
Parallel IDE Connector
Serial ATA Port1/3 Connector
Audio S/PDIF-OUT Connector
Audio CD-In Connector
SM Bus Connector
USB Port7/8 Connector
Front Panel Bezel Connector
SPI Flash Record Connector
Mini PCI-Express Socket (Optional)
Compact Flash Connector(Optional)
PCI-Express x16 Slot
PCI-Express x4 Expansion Slot
DDRII Long-DIMM 2
DDRII Long-DIMM 1
NB FAN Connector
Jumpers and Connectors
Downloaded from StockCheck.com
SBC86840 Series All-In-One Mini ITX Board User's Manual

Connectors

Connectors Label
CN1
CN2
CN3
CN4
CN5
CN6
CN7
CN8
CN9
CN10
CN11
CN12
CN13
CN14
CN15
CN16
CN17
CN18
CN19
CN20
CN21
CN22
CN23
CN24
CNS1
CNS2
PCIE1
PCIE2
DDR1
DDR2
FAN1
