SBC86840 Series All-In-One Mini ITX Board User's Manual
On-Chip Frame Buffer Size
Use this item to set the VGA frame buffer size.
DVMT Mode
DVMT (Dynamic Video Memory Technology) helps you select the
video mode.
DVMT/Fixed Memory Size
DVMT (Dynamic Video Memory Technology) allows you to select a
maximum size of dynamic amount usage of the video memory. The
system would configure the video memory dependent on your
application.
Boot Display
This item is to select Display Device that the screen will be shown.
Panel Scaling
This item shows the setting of panel scaling and operates the
scaling function that the panel output can fit the screen resolution
connected to the output port.
Panel Number
This item is to select panel resolution that you want.
TV Standard
This item is to select the output mode of TV Standard.
TV Connector
This item is to select the type of TV display connector.
Press <Esc> to return to the Main Menu page.
Award BIOS Utility
58
