SBC86840 Series All-In-One Mini ITX Board User's Manual
Max Saving
User Define
Min Saving
Disabled
V/H
SYNC+Blank
DPMS
Blank Screen
66
Downloaded from StockCheck.com
ACPI Suspend Type
This item specifies the power saving modes for ACPI function. If
your operating system supports ACPI, such as Windows 98SE,
Windows ME and Windows 2000, you can choose to enter the
Standby mode in S1 (POS) or S3 (STR) fashion through the setting
of this field. Options are:
[S1 (POS)] The S1 sleep mode is a low power state. In this
state, no system context is lost (CPU or chipset) and
hardware maintains all system contexts.
[S3 (STR)] The S3 sleep mode is a lower power state where
the information of system configuration and open
applications/files is saved to main memory that remains
powered while most other hardware components turn off to
save energy. The information stored in memory will be used
to restore the system when a "wake up" event occurs.
Power Management
This option allows you to select the type (or degree) of power
saving for Doze, Standby, and Suspend modes. The table below
describes each power management mode:
It is maximum power savings, only available for SL CPUs.
The inactivity period is 1 minute in each mode.
It sets each mode. Select time-out periods in the PM
Timers section.
It is minimum power savings. The inactivity period is 1
hour in each mode (except the hard drive).
Default value
Video Off Method
This setting determines the manner in which the monitor is blanked.
It turns OFF vertical and horizontal synchronization ports
and writes blanks to the video buffer.
Select this option if your monitor supports the Display
Power Management Signaling (DPMS) standard of the
Video Electronics Standards Association (VESA). Use
the supplied software for your video subsystem to select
video power management values.
The System only writes blanks to the video buffer.
Video Off In Suspend
This item defines if the video is powered down when the system is
put into suspend mode.
