SBC86840 Series All-In-One Mini ITX Board User's Manual
C h a p t e r 1
Introduction
®
TM
The SBC86840, a Mini ITX board, supports Intel
Core
2 Duo and
®
Celeron
M processors with graphics, audio, and Gigabit Ethernet
interfaces. It is practically finest embedded Socket P board in the
®
market. It integrates Intel
GME965 & ICH8M chipsets, excellent
Multiple I/O, LVDS LCD, Gigabit Ethernet and HD digital Audio
interface to make all in one single module as computing engine. It
provides one PCI Express X16 for graphics for expansion purpose.
Additionally, it provides you with unique embedded features, such as
four serial ports (three RS-232 and one RS-232/422/485) and Mini
ITX form factor that applies an extensive array of PC peripherals.
This module supports various I/O features: CRT, LVDS LCD, Gigabit
Ethernet, HD Audio, PATA IDE, SATA IDE, USB 2.0, GPIO and
Watchdog timer.
Introduction
1
