Table 18 on page 33 shows the model number, description of the line card model, and
the Junos OS release in which the line card was first supported.

Table 18: EX9200-4QS Line Card

Model Description
EX9200-4QS A line card with four 40-Gigabit Ethernet quad small
form-factor pluggable plus (QSFP+) ports, each of
which can house 40-gigabit quad small form-factor
pluggable plus (QSFP+) transceivers
See Figure 20 on page 33.

Figure 20: EX9200-4QS Line Card

1— Ejector lever
2— Line card LED
3—MIC LED
You can use the show version
switches loaded on the switch.
The EX9200-4QS line card has:
Four QSFP+ ports, each of which can house QSFP+ transceivers.
Four dust covers preinstalled in the QSFP+ ports.
Line card status LED—An LED labeled
See Line Card LED in an EX9200 Switch.
MIC LED—An LED labeled
"Modular Interface Card LED in an EX9200 Switch" on page
Network port LED—An LED labeled
link activity of the port. See
Line Card Model and Version Compatibility in an EX9200 Switch on page 35
Pluggable Transceivers Supported on EX9200 Switches on page 37
Chapter 2: Updated Common EX9200 Topics
4— LEDs for QSFP+ ports
5— QSFP+ports
command to see the version of Junos OS for EX Series
indicates the status of the line card.
OK/FAIL
on each MIC indicates the status of the MIC. See
OK/FAIL
located next to the network port indicates the
Link
"Network Port LEDs in an EX9200 Switch" on page
Junos OS Release
Required
12.3R2 or later
5.
15.
33
