4. Attach the lens cover.
5. Attach the main unit cover and turn it
clockwise (in the direction indicated by
arrows).

[3] Drawing the Composite Cable from the Camera Back Face

1.Remove the blank cover from the back face of the Camera base , and draw the
composite cable from the back face of the Camera.
BLANK COVER
MAIN UNIT
LENS COVER
MAIN UNIT
MAIN UNIT COVER
- 13 -
MAIN UNIT COVER
COMPOSITE
CABLE
