Symptom
The Ethernet cable The Ethernet connector (RJ45) is provided in the
cannot be
connected
The Ethernet
connector link
indicator lamp
does not light.
The PC cannot
be connected to
the Camera.
back ofthe Camera.
• The power to the Camera or a device connected to it
is not turned ON.
Confirm that the cable is connected securely, and
turn ON the power.
• The Ethernet cable is broken.
Check if continuity appears across cable connector
terminals.
• A wrong cable is used.
Basically, use a "Ethernet cross cable (supplied)"
when a PC is connected to the Camera, or a
"straight cable"when a hub or router is used.
Check the specifications of the device to be con-
nected.
When the PoE is used, make the connection by
using the connection method for the PoE load
dispatching device.
• The IP address of the Camera is not designated.
Designate the IP address set in the Camera.
• The IP address set on the PC does not match the
network.
The connection from a client to the Camera
requires the network address to be the same (192.
168.1.* when the Camera is in the initial setting).
•The setting for the router is not correct.
Check the network configuration of the Camera
and PC, and set the router correctly.
* If you have forgotten the IP address of the
Camera, see "5.INITIALIZING THE SETTING
state (page 17)".
Checking Point
- 85 -
Ref.
Page
P. 7
–
–
P. 19,
20
P. 23,
32, 48,
54
P. 19,
20
P. 19,
20
