Elmo TND4004 Instruction Manual

Color ccd tv dome camera
Hide thumbs Also See for TND4004:

Advertisement

Quick Links

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION
· Do not use any power supply other than
specified.
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
* The CAUTION label is attached on the back
of camera.
T N D 4 0 0 4
D O M E C A M E R A
I N S T R U C T I O N M A N U A L
INFORMATION
This equipment has been tested and
found to comply with the limits for Class A
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference when the equipment
is operated in a commercial environment.
This equipment generates, use, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a
residential area is likely to cause harmful
interference in which case the user will be
required to correct the interference at his
own expense.
USER-INSTALLER CAUTION:
authority to operate this FCC verified
equipment could be voided if you make
changes or modifications not expressly
approved by the party responsible for
compliance to Part of the FCC Rules.
Your

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TND4004 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Elmo TND4004

  • Page 1 I N S T R U C T I O N M A N U A L CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings, install in accordance with the manufacture's instructions. 8.
  • Page 3: Appearance View

    : 36° (TELE) ~ 72° (WIDE) Auto Main body : White Cover : Black Diameter : 116mm (4.6") 0.5 kg (1.1 lbs) -10°C ~ +50°C (14°F~122°F) 30% ~ 90% - 2 - Unit : mm (inch) TND4004 Height : 106mm (4.2") without protruded part...
  • Page 4: Name And Function Of Each Part

    3. Name and Function of Each Part Metal fitting For mounting on the ceiling or wall. Hook (3 locations) For temporarily fixing the main body. Main body The main body of a camera section. Dome cover A protective cover for the lens section. AC/DC power terminal Connect this to the AC24V 60Hz or DC12V power supply.
  • Page 5 Tilt lock screw For locking the tilt after adjusting the image up/down direction. Pan lock screw For locking the pan after adjusting the image right/left direction. Zoom ring For adjusting the image size. Focus ring For adjusting the focus. PUSH button ·...
  • Page 6 Selector switch (details) a. White balance selector Combination of the switch 1, 2, and 3, the following adjustments are available: 1. ATW (AWB) The camera adjusts the white balance by automatically following the color temperature change within the pull- in color temperature range. The pull-in color temperature range is from approx.
  • Page 7: How To Set Up

    4. How to Set Up 4-1 How to Install and Adjust Recommended mounting surface is wood or dry wall. (1) Make a round hole of 70mm OD (2.76") to the mounting surface where the camera is to be mounted. (Refer to Fig.1) (2) Attach coaxial cable and power cord to the POWER &...
  • Page 8 (5) Remove the dome cover from the main body. Remove the dome cover by turning it counterclockwise (arrow direction) (Fig. 4). (6) Mount the body to the metal fitting. Match the positioning mark on the main body with the on the metal fitting, and mark thrust the main body toward the metal fitting.
  • Page 9 (8) While watching the monitor, adjust the image direction. · Right/left direction (Fig. 8) Loosen the pan lock screw, turn the base right and left, and adjust the right/left direction. After setting the right/left direction, tightly fasten the pan lock screw. * If the pan lock screw is not tightly fastened, the base may turn when the dome cover is mounted.
  • Page 10 (11) Adjust the focus with the focus ring (Fig. 12). * Adjust the focus after adjusting the angle of view. (12) Match the "I" mark on the lens with the recessed portion of the camera holder (Fig. 13). * Be sure to match them, or the dome cover may not be mounted in same lens position.
  • Page 11: How To Connect The Cables

    4-2 How to Connect the Cables (1) Prepare the coaxial cable end as shown (Fig. 15). (2) Connect the coaxial cable and power cables to the terminal strip. Insert the core underneath of the appropriate locking washer fitting, and fasten the screw. Secure the shielding wire to the coaxial cable fixing metal fitting with the screws (Fig.
  • Page 12 * Upon completion of any service or repairs to this video product ask the service technician to perform safety checks to determine that video product is in proper operating condition. ELMO Canada Mfg. Corp. 44 West Drive, Brampton, Ontario, L6T 3T6, Canada Tel.
