Elmo TD4114 IP II Instruction Manual page 79

Name
Matched Designate the size of JPEG images to be attached
Resolution when transmitting the FTP or transmitting e-mail as
(Alarm 2) set at Alarm 2 Action.
Half-D1/SIF/QQVGA
Motion Set any desired title of Motion Detection.
Detection Two-byte characters, including Japanese characters,
Title are not available for a title.
Use one-byte alphanumerical characters.
Motion Select an alarm action to take place when an action is
Detection detected under the action detection settings made on
Action Viewer.
None: No action will take place.
Send FTP: The JPEG file of the obtained snapshot
will be transmitted by FTP.
Send E-Mail: E-mail will be transmitted.
Both: The JPEG file of the obtained snapshot will be
transmitted by FTP and e-mail will be transmitted at the
same time.
Matched Designate the size of JPEG images to be attached
Resolution when transmitting the FTP or transmitting e-mail as
(Motion set at Motion Detection Action.
Detection) Half-D1/SIF/QQVGA
Alarm 1 An alarm output signal (open collector output) will
Output be output to alarm IN-OUT terminal (six-pin
connector (black)) pin 5 "ALARM OUT (black)"
when alarm 1 is activated.
Alarm 2 An alarm output signal (open collector output) will
Output be output to alarm IN-OUT terminal (six-pin
connector (black)) pin 5 "ALARM OUT (black)"
when alarm 2 is activated.
Motion An alarm output signal (open collector output) will
Detection be output to alarm IN-OUT terminal (six-pin
Alarm Out connector (black)) pin 5 "ALARM OUT (black)"
when a motion is detected.
Function
- 78 -
Factory settings
SIF
Motion
Detection
None
SIF
None
None
None
