[5] Set items

G AE Settings
Name
E-ZOOM To set the maximum magnification [OFF, 1.1x, 1.2x,
1.4x, 1.6x, 1.8x, 2.0x, 2.2x, 2.4x, 2.6x, 2.8x, 3.0x, 3.5x,
4.0x]
HS-SHUTTER To select the high-speed shutter speed [OFF (1/60s),
1/100s, 1/250s, 1/500s, 1/1000s, 1/2000s, 1/4000s,
1/10000s, 1/20000s, 1/50000s].
When [LS-SHUTTER] is [ON], the shutter speed can
be selected from [OFF (1/60s) 1/100s].
If the shimmer of fluorescent lamp is annoying when
the shutter speed is set to [OFF (1/60s), set the shutter
speed to [1/100s], and the shimmer will be eased.
LS-SHUTTER To set the low-speed shutter (electronic sensitivity up)
to [ON/OFF]. When the object becomes dark, this
function automatically varies the CCD accumulated time
across several fields up to the set maximum level to
optimize the brightness of the object.
LS-MAX To set the maximum number of fields of the low-speed
shutter [2fields, 3fields, 4fields, 5fields, 6fields, 8fields,
12fields, 20fields, 40fields, 80fields].
If the CCD accumulated time is set longer, the image
frame rate will decrease, and moving object could not
be seen well.
PRIORITY To select the image attributes [MOTION, COLOR, S/N
(fineness)] to be prioritized when [LS-SHUTTER] is
selected and the object becomes dark.
ICR To set the DAY/NIGHT function (IR cut filter removable OFF
function).When this function is set to [AUTO], the filter
is attached/removed automatically according to the
brightness. When the IR cut filter is removed, the color
image is switched to B&W image.
AGC GAIN To set the maximum gain of the AGC [0dB, 4dB, 8dB,
12dB,16dB, 20dB, 24dB].
The AGC is a function of amplifying the signal from the
CCD to make the object visible when the object
becomes dark.
Function
- 72 -
Factory settings
OFF
OFF
OFF
4fields
MOTION
8dB
