G External GPIO
Name
Activation Set the output mode.
Mode Normal Open: High impedance is usually activated,
and the GND level becomes valid during output.
Normal Close: The GND level is usually activated,
and high impedance becomes valid during output.
G MPEG4
Make settings for MPEG4 display using "ELMO 1Channel Viewer".
Name
Quality Designate the upper limit to the data amount to limit
the data amount generated during communication or
image distribution.
Frame: 500 - 2000 (kbps)
GOP:64 - 2000 (kbps)
Framerate Designate the number of frames to be displayed per
second.
(setting range: 30, 15, 10, 5, and 1 frames/second).
Resolution Designate the size of images to be displayed.
D1 (704 x 480) , SIF(352 x 240)
Mode Set a delay for images according to the network
environment.
Frame: Reduces the delay for images.
GOP: Enables live images to be viewed even on a
poor-performance network although the delay for
images is long.
G JPEG
Make settings for motion JPEG display and capture display using a browser and for
snapshot acquisition using "ELMO 1Channel Viewer".
Name
JPEG Designate image quality.
Quality High: High image quality.
Normal: Medium image quality with a compression
rate between High and Low.
Low: Low image quality.
Function
Function
Function
- 75 -
Factory settings
Normal
Open
Factory settings
2000(kbps)
30(frames/
second)
D1
Frame
Factory settings
Normal
