G Alarm
Name
Alarm 1 Title Set any desired title of alarm 1.
* Two-byte characters, including Japanese characters,
are not available for a title.
Use one-byte alphanumerical characters.
Alarm 1 Select the mode of the alarm to be effective when
Action an alarm input signal (no-voltage make contact) is
input to alarm IN-OUT terminal (six-pin
connector (black)) pin 1 "ALARM IN1 (blue)".
None: No action will take place.
Send FTP: The JPEG file of the obtained snapshot
will be transmitted by FTP.
Send E-Mail: E-mail will be transmitted.
Both: The JPEG file of the obtained snapshot will be
transmitted by FTP and e-mail will be transmitted at the
same time.
Matched Designate the size of JPEG images to be attached
Resolution when transmitting the FTP or transmitting e-mail as
(Alarm 1) set at Alarm 1 Action.
Half-D1/SIF/QQVGA
Alarm 2 Title Set any desired title of alarm 2.
* Two-byte characters, including Japanese characters,
are not available for a title.
Use one-byte alphanumerical characters.
Alarm 2 Select the mode of the alarm to be effective when
Action an alarm input signal (no-voltage make contact) is
input to alarm IN-OUT terminal (six-pin
connector (black)) pin 3 "ALARM IN2 (gray)".
None: No action will take place.
Send FTP: The JPEG file of the obtained snapshot
will be transferred by FTP.
Send E-Mail: E-mail will be transmitted.
Both: The JPEG file of the obtained snapshot will be
transferred by FTP and e-mail will be transmitted at the
same time.
Function
- 77 -
Factory settings
Event1
None
SIF
Event2
None
