Summary of Contents for Allied Telesis IE200 Series
- Page 1 IE200 Series Industrial Ethernet Switches AT-IE200-6FT AT-IE200-6FP AT-IE200-6GT AT-IE200-6GP Installation Guide 613-001837 Rev. D...
- Page 2 Allied Telesis, Inc. has been advised of, known, or should have known, the...
- Page 3 European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment This Allied Telesis RoHS-compliant product conforms to the European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment. Allied Telesis ensures RoHS conformance by requiring supplier Declarations of Conformity, monitoring incoming materials, and maintaining manufacturing process controls.
- Page 4 IE200 Series Installation Guide RFI Immunity EN55024 EN61000-4-2 EN61000-4-3 EN61000-4-4 EN61000-4-5 EN61000-4-6 EN61000-4-8 EN61000-4-11 Electrical and Laser Safety UL/E/IEC60950-1 CSA 22.2:60950-1 2014/35/EU Low Voltage Directive Shock EN60068-2-27 Free Fall EN60068-2-31 Vibration EN60068-2-6 Outdoor Enclosure Safety UL/IEC/EN60950-22 Allied Telesis approved SFP modules...
- Page 5 IE200 Series Installation Guide Translated Safety Statements Important: The indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” on our web site at http://www.alliedtelesis.com/support.
-
Page 7: Table Of Contents
Contents Preface ....................................13 Safety Symbols Used in this Document..........................14 Contacting Allied Telesis ..............................15 Chapter 1: Overview ................................ 17 Hardware Components................................18 Features ....................................23 Twisted Pair Ports ................................23 Power Over Ethernet ..............................23 SFP Slots ..................................23 LEDs.....................................24 Alarm Connectors.................................24 MAC Address Tables ..............................24 Management Software ..............................24... - Page 8 Contents Chapter 2: Beginning the Installation ..........................49 Reviewing Safety Precautions ............................50 Safety Precautions When Working with Electricity ......................54 Reviewing Site Requirements............................. 55 Verifying the Package Contents............................57 Chapter 3: Installing the Switch ............................. 61 Installing the Switch on a DIN Rail............................62 Installing the Switch on a Wood Wall..........................
- Page 9 Figures Figure 1: Front Panel of the AT-IE200-6FT Switch.......................18 Figure 2: Front Panel of the AT-IE200-6FP Switch ......................19 Figure 3: Front Panel of the AT-IE200-6GT Switch ......................20 Figure 4: Front Panel of the AT-IE200-6GP Switch......................21 Figure 5: Top Panel ................................21 Figure 6: Back Panel Features .............................22 Figure 7: Example 1 of the Alarm In (ALM IN) Connector ....................37 Figure 8: Example 2 of the Alarm In (ALM IN) Connector ....................38...
- Page 10 Figures Figure 50: Installing the Optional Drip Guard........................99 Figure 51: Securing the Drip Guard ............................100 Figure 52: RJ-45 Port Pin Layout (Front View) ........................114 Figure 53: Console Port Pin Layout (Front View) .......................116...
- Page 11 Tables Table 1: Twisted Pair Cables ...............................27 Table 2: Maximum Power Levels ............................28 Table 3: Twisted Pair Cable for Powered Devices on the AT-IE200-6FP and AT-IE200-6GP Switches ......29 Table 4: PoE and PoE+ Powered Device Classes ......................29 Table 5: Maximum Installation Site Temperatures Versus SFP Temperature Ratings ............32 Table 6: Status LEDs ................................41 Table 7: Twisted Pair Port LEDs on the AT-IE200-6FT Switch ...................42 Table 8: Twisted Pair Port LEDs on the AT-IE200-6GT Switch ...................43...
- Page 12 Tables...
-
Page 13: Preface
Preface This guide contains the hardware installation instructions for the IE200 Series of industrial managed switches. The preface contains the following sections: “Safety Symbols Used in this Document” on page 14 “Contacting Allied Telesis” on page 15... -
Page 14: Safety Symbols Used In This Document
Preface Safety Symbols Used in this Document This document uses the following conventions. Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings inform you that performing or omitting a specific action may result in bodily injury. -
Page 15: Contacting Allied Telesis
IE200 Series Installation Guide Contacting Allied Telesis If you need assistance with this product, you may contact Allied Telesis technical support by going to the Support & Services section of the Allied Telesis web site at www.alliedtelesis.com/support. You can find links for the following services on this page: ... - Page 16 Preface...
-
Page 17: Chapter 1: Overview
Chapter 1 Overview This chapter describes the hardware features of the IE200 Series of managed industrial switches. The sections in the chapter are listed here: “Hardware Components” on page 18 “Features” on page 23 “Twisted Pair Ports” on page 26 ... -
Page 18: Hardware Components
Chapter 1: Overview Hardware Components The switches in the IE200 Series are listed here: AT-IE200-6FT AT-IE200-6FP AT-IE200-6GT AT-IE200-6GP The front panel of the AT-IE200-6FT Switch is shown in Figure 1. Status LEDs Four 10/100Base-TX Reset button... -
Page 19: Figure 2: Front Panel Of The At-Ie200-6Fp Switch
IE200 Series Installation Guide The front panel of the AT-IE200-6FP Switch is shown in Figure 2. Status LEDs Four 10/100Base-TX Reset button twisted pair ports with PoE and PoE+ Console management port Two slots for 100/1000Base-FX SFP transceivers USB port... -
Page 20: Figure 3: Front Panel Of The At-Ie200-6Gt Switch
Chapter 1: Overview The front panel of the AT-IE200-6GT Switch is shown in Figure 3. Status LEDs Four 10/100/1000Base-T Reset button twisted pair ports Console management port Two slots for 100/1000Base-FX SFP transceivers USB port Figure 3. Front Panel of the AT-IE200-6GT Switch... -
Page 21: Figure 4: Front Panel Of The At-Ie200-6Gp Switch
IE200 Series Installation Guide The front panel of the AT-IE200-6GP Switch is shown in Figure 4. Status LEDs Four 10/100/1000Base-T Reset button twisted pair ports with PoE and PoE+ Console management port Two slots for 100/1000Base-FX SFP transceivers USB port Figure 4. -
Page 22: Figure 6: Back Panel Features
Chapter 1: Overview Figure 6 identifies the components on the back panel. Screw holes for wall bracket DIN rail bracket Screw holes for wall bracket Figure 6. Back Panel Features... -
Page 23: Features
IE200 Series Installation Guide Features Here are the basic features of the switches. Twisted Pair Here are the basic features of the twisted pair ports: Ports 4 ports per switch 10Base-T and 100Base-TX compliant on the AT-IE200-6FT and AT-IE200-6FP Switches ... -
Page 24: Leds
Chapter 1: Overview LEDs The switches have the following LEDs: Link/activity and duplex mode LEDs for the twisted pair ports on the AT-IE200-6FT and AT-IE200-6GT Switches. Link/activity and PoE status LEDs for the twisted pair ports on the AT-IE200-6FP and AT-IE200-6GP Switches. - Page 25 IE200 Series Installation Guide Extended environmental range IP30-compliant without optional drip guard IP31-compliant with optional drip guard RJ-45 style Console port for local management...
-
Page 26: Twisted Pair Ports
Chapter 1: Overview Twisted Pair Ports This section describes the four twisted pair ports. Connector Type The twisted-pair ports have 8-pin RJ-45 connectors. The ports use four pins at 10 or 100 Mbps and all eight pins at 1000 Mbps. The pin assignments are listed in Table 25 on page 114 and Table 26 on page 114. -
Page 27: Cable Requirements
IE200 Series Installation Guide Cable The cable requirements for the twisted pair ports are listed in Table 1. Requirements Table 1. Twisted Pair Cables Cable Type 10Mbps 100Mbps 1000Mbps Standard TIA/EIA 568-B- compliant Category 3 shielded or unshielded cabling with 100 ohm impedance and a frequency of 16 MHz. -
Page 28: Power Over Ethernet
Chapter 1: Overview Power over Ethernet Ports 1 to 4 on the AT-IE200-6FP and AT-IE200-6GP Switches support Power over Ethernet (PoE). With PoE, the switch can supply electrical power to network devices over the same twisted pair cables that carry network traffic. -
Page 29: Powered Device Classes For Poe And Poe
IE200 Series Installation Guide Table 3. Twisted Pair Cable for Powered Devices on the AT-IE200-6FP and AT-IE200-6GP Switches 10Mbps 100Mbps 1000Mbps Cable Type PoE+ PoE+ PoE+ Standard TIA/EIA 568- B-compliant Category 3 shielded or unshielded cabling with 100 ohm impedance and a frequency of 16 MHz. -
Page 30: Poe Wiring
Chapter 1: Overview Table 4. PoE and PoE+ Powered Device Classes (Continued) Maximum Power Output PD Power Class Usage at the Switch Range Port Optional 15.4W 6.49W to 12.95W Optional 30.0W 12.95W to 25.9W PoE Wiring The IEEE 802.3af and 802.3at standards define two methods for delivering power to powered devices over the four pairs of strands in standard Ethernet twisted-pair cable. -
Page 31: Port Prioritization
IE200 Series Installation Guide plan to connect to the switch exceed its power budget, refer to their documentation for their power requirements and add the requirements together. The switch should be able to power all the devices simultaneously as long as the total is below its power budget of 120W. If the total exceeds the available power budget, you should consider reducing the number of PoE devices so that all the devices receive power. -
Page 32: Sfp Slots
Chapter 1: Overview SFP Slots The two SFP slots support Ethernet 100/1000Base fiber optic, MSA- compliant SFP transceivers. You can use transceivers to connect switches to other network devices over large distances, build a high-speed backbone network between network devices, or connect high-speed devices, such as servers, to your network. -
Page 33: Console Port
IE200 Series Installation Guide Console Port The Console port is a serial RS-232 port. You use it to access the AlliedWare Plus management software and configure the features. Management sessions conducted through the Console port are called local management sessions because you have to be at the location of the switch. -
Page 34: Usb Port
Chapter 1: Overview USB Port The USB port supports a flash drive for the following management functions: Use Allied Telesis Management Framework to provide a centralized network backup location. Store backup copies of configuration files. Transfer configuration files between switches. -
Page 35: Ground Screw
Un-interruptible power supplies The power supply requirements are described in “Power Supplies” on page 47. Allied Telesis does not sell power supplies for this product. They must be purchased from another equipment manufacturer. Note The AT-iMG008 Power Supply and Backup Unit from Allied Telesis... -
Page 36: Alarm In Connector
AlliedWare Plus operating system to specify the state of the external sensor that signals an alarm. Alarms remain active until their causes are resolved. For instructions on the command, refer to the Software Reference for IE200 Series Switches. Here are the requirements for the external sensor: ... -
Page 37: Figure 7: Example 1 Of The Alarm In (Alm In) Connector
IE200 Series Installation Guide The example in Figure 7 shows the Alarm In connector attached to a door sensor. The sensor is installed such that it is closed (on) when the door is closed and open (off) when the door is open. -
Page 38: Figure 8: Example 2 Of The Alarm In (Alm In) Connector
The command configures the switch to signal the alarm when the sensor changes to closed above 30° C. When the temperature falls below 30° C, and the temperature sensor changes from closed to open, the switch automatically cancels the alarm. External sensors are not available from Allied Telesis. -
Page 39: Alarm Out Connector
IE200 Series Installation Guide Alarm Out Connector The 2-pin Alarm Out connector on the top panel of the switch is for an external alert device. The switch uses the device to alert you to alarm conditions, such as power supply failures or ports without links. Here are two examples of alert devices for the Alarm Out connector: ... -
Page 40: Din Rail Bracket
The alert device, detecting the change to the circuit, turns on the LED. When the switch detects that all its ports have links again, it closes the circuit, which turns off the LED. Alarm devices are not available from Allied Telesis. Blue LED Circuit closed - LED off Circuit open - LED on Figure 9. -
Page 41: Leds
1 does not have a link to a network device: alarm facility link-down port1.0.1 led For more information, refer to the Software Reference for IE200 Series Switches or Command Reference for IE200 Series Switches. Six flashes The switch is overheating and might shut in two down. -
Page 42: Twisted Pair Port Leds
Chapter 1: Overview Table 6. Status LEDs (Continued) State Description Solid Green The switch is receiving power on the PWR 1 connector and is operating normally. PWR2 The switch is not receiving power on the PWR 2 connector or the input power from the DC power supply is outside the normal operating range of the unit. -
Page 43: Table 8: Twisted Pair Port Leds On The At-Ie200-6Gt Switch
IE200 Series Installation Guide Table 7. Twisted Pair Port LEDs on the AT-IE200-6FT Switch State Description Solid Green The port has established a 100 Mbps link to a network device. Flashing The port is transmitting or receiving data at Green 100 Mbps. -
Page 44: Figure 11: Twisted Pair Ports On The At-Ie200-6Fp And At-Ie200-6Gp Switches
Chapter 1: Overview Power over Ethernet Speed and activity Figure 11. Twisted Pair Ports on the AT-IE200-6FP and AT-IE200-6GP Switches The states of the LEDs on the twisted pair ports on the AT-IE200-6FP Switch are defined in Table 10. Table 9. Twisted Pair Port LEDs on the AT-IE200-6FP Switch State Description Solid Green... -
Page 45: Table 10: Twisted Pair Port Leds On The At-Ie200-6Gp Switch
IE200 Series Installation Guide Table 9. Twisted Pair Port LEDs on the AT-IE200-6FP Switch State Description Solid Green The port has established a 100 Mbps link to a network device. Flashing The port is transmitting or receiving data at 100 Green Mbps. -
Page 46: Sfp Slot Leds
Chapter 1: Overview Table 10. Twisted Pair Port LEDs on the AT-IE200-6GP Switch State Description Solid Green The port has established a 1000 Mbps link to a network device. Flashing The port is transmitting or receiving data at 1000 Green Mbps. -
Page 47: Power Supplies
IE200 Series Installation Guide Power Supplies Allied Telesis does not sell power supplies for these products. Power supplies can be purchased from power supply manufacturers. The AT-IE200-6FT and AT-IE200-6GT Switches have the following power supply requirements: DC voltage between 12 and 48VDC. -
Page 48: Optional Drip Guard
IP31. Figure 12. Optional Drip Guard Note Be sure to specify the IE200 Series switches when ordering the drip guard. The IE300 Series switches also have a drip guard, but that guard does not fit on IE200 Series switches. -
Page 49: Chapter 2: Beginning The Installation
Chapter 2 Beginning the Installation The chapter contains the following sections: “Reviewing Safety Precautions” on page 50 “Safety Precautions When Working with Electricity” on page 54 “Reviewing Site Requirements” on page 55 “Verifying the Package Contents” on page 57... -
Page 50: Reviewing Safety Precautions
Chapter 2: Beginning the Installation Reviewing Safety Precautions Please review the following safety precautions before beginning the installation procedures. Note Safety statements that have the symbol are translated into multiple languages in the Translated Safety Statements document at www.alliedtelesis.com/support. Warning Class 1 Laser product. - Page 51 IE200 Series Installation Guide Warning Power cord is used as a disconnection device. To de-energize equipment, disconnect the power cord. E3 Warning This equipment must be earthed. The ground screw on the unit must be connected to a properly earthed bonding point.
- Page 52 Chapter 2: Beginning the Installation Warning To reduce the risk of electric shock, do not route network cables from PoE ports outside the building that houses this device. E40 Caution The unit does not contain serviceable components. Please return damaged units for servicing.
- Page 53 IE200 Series Installation Guide Warning Allied Telesis does not warrant against lightning or power surges causing damage the device. Such damage will be the responsibility of the equipment owner.
-
Page 54: Safety Precautions When Working With Electricity
Chapter 2: Beginning the Installation Safety Precautions When Working with Electricity Please review the following additional safety guidelines before beginning the installation procedure. Disconnect all power by turning off the circuit breakers before installing or removing the device or when working with the power supplies. -
Page 55: Reviewing Site Requirements
IE200 Series Installation Guide Reviewing Site Requirements Please observe the following requirements and guidelines when choosing a site for the switch: You can install the switch on a concrete wall, wooden wall, or DIN 35x7.5mm rail. You should not install the switch on a wall that has metal studs. -
Page 56: Table 12: Ground Resistivity Recommendations
Chapter 2: Beginning the Installation restrictions on site requirements, and to follow all guidelines and safety warnings. The switch and DC power source should be installed close to each other so that the DC power cables are kept as short as possible to minimize voltage loss. -
Page 57: Verifying The Package Contents
IE200 Series Installation Guide Verifying the Package Contents Figure 13 identifies the pre-installed components on the front panel of the switch. Five dust covers on the twisted pair ports and Console port Two dust covers on the SFP slots One dust cover on the USB port... -
Page 58: Figure 14: Pre-Installed Components On The Top Panel
Chapter 2: Beginning the Installation Figure 14 identifies the pre-installed components on the top panel. Two 2-pin connectors on the DC ALM IN and ALM OUT connectors One 4-pin connector on the DC PWR 1 and PWR 2 power connectors One M4x8 Phillips-head grounding screw Figure 14. -
Page 59: Figure 15: Pre-Installed Component On The Back Panel
IE200 Series Installation Guide Figure 15 identifies the pre-installed component on the back panel. One DIN rail bracket Figure 15. Pre-installed Component on the Back Panel... -
Page 60: Figure 16: Components In The Accessory Kit
Chapter 2: Beginning the Installation Figure 16 lists the items in the accessory kit included with the switch. Two wall brackets Five M4x8 Phillips-head screws One 2 m (6.6 ft) local management cable with RJ-45 (8P8C) and DB-9 (D-sub 9-pin) connectors Figure 16. -
Page 61: Chapter 3: Installing The Switch
Chapter 3 Installing the Switch The procedures in this chapter are listed here: “Installing the Switch on a DIN Rail” on page 62 “Installing the Switch on a Wood Wall” on page 65 “Installing the Switch on a Concrete Wall” on page 67... -
Page 62: Installing The Switch On A Din Rail
Chapter 3: Installing the Switch Installing the Switch on a DIN Rail The switch comes with a DIN rail bracket pre-installed on the back panel. The bracket is compatible with DIN 35x7.5mm rails. Figure 17 shows the proper orientation of the switch on a DIN rail. Do not install the switch horizontally or upside-down. -
Page 63: Figure 18: Installing The Switch On A Din Rail - 1
IE200 Series Installation Guide Slot in DIN rail bracket Top edge of DIN rail Figure 18. Installing the Switch on a DIN Rail - 1 2. Press on the bottom edge of the front faceplate of the switch until the bottom edge of the DIN rail snaps into the bottom slot of the bracket. -
Page 64: Figure 20: Verifying The Din Rail Installation
Allied Telesis recommends installing DIN rail end clamps to the sides of the switch to prevent damage or network traffic loss from vibration or shock. End clamps are not available from Allied Telesis. 4. Go to Chapter 4, “Cabling the Ports” on page 71. -
Page 65: Installing The Switch On A Wood Wall
IE200 Series Installation Guide Installing the Switch on a Wood Wall This section contains instructions on how to install the switch on a wood stud in a wall. Here are the tools and material required for installing the switch on a wall with wooden studs: ... -
Page 66: Figure 22: Attaching The Switch To The Wall
Chapter 3: Installing the Switch The selected wall location for the base should adhere to the recommendations in “Reviewing Site Requirements” on page 55. 3. Hold the switch on the wall and secure it with four screws (not provided). Refer to Figure 22. Please follow these guidelines as you position the switch on the wall: ... -
Page 67: Installing The Switch On A Concrete Wall
IE200 Series Installation Guide Installing the Switch on a Concrete Wall This section contains instructions on how to install the switch on a concrete wall. Here are the tools and material required for installing the switch on a concrete wall: ... -
Page 68: Figure 23: Marking The Locations Of The Bracket Holes On A Concrete Wall
Prior to drilling, set the drill to hammer and rotation mode. The modes break up the concrete and clean out the hole. Allied Telesis recommends cleaning out the holes with a brush or compressed air. 6. Insert four anchors (not provided) into the holes. -
Page 69: Figure 24: Installing The Switch On A Concrete Wall
IE200 Series Installation Guide Figure 24. Installing the Switch on a Concrete Wall 8. Go to Chapter 4, “Cabling the Ports” on page 71. - Page 70 Chapter 3: Installing the Switch...
-
Page 71: Chapter 4: Cabling The Ports
Chapter 4 Cabling the Ports This chapter contains the following procedures: “Cabling the Twisted Pair Ports” on page 72 “Installing SFP Transceivers” on page 74... -
Page 72: Cabling The Twisted Pair Ports
Chapter 4: Cabling the Ports Cabling the Twisted Pair Ports Here are the guidelines to cabling the 10/100/1000Base-T twisted pair ports on the cards: The ports have 8-pin RJ45 connectors. The cable specifications for the twisted pair ports on the AT-IE200- 6FT and AT-IE200-6GT Switches are listed in Table 1 on page 27. - Page 73 IE200 Series Installation Guide automatic MDIX detection and set the wiring configuration manually with the POLARITY command. The appropriate MDI/MDI-X setting for a switch port connected to a 10/100Base-T network device with a fixed wiring configuration depends on the setting of the network device and whether the switch and network device are connected with straight-through or crossover cable.
-
Page 74: Installing Sfp Transceivers
Chapter 4: Cabling the Ports Installing SFP Transceivers Please review the following guidelines before installing SFP transceivers: SFP transceivers are hot-swappable. You may install them while the device is powered on. For a list of supported transceivers, refer to the product datasheet. ... -
Page 75: Figure 25: Removing The Dust Plug From An Sfp Slot
IE200 Series Installation Guide Figure 25. Removing the Dust Plug from an SFP Slot 2. Remove the transceiver from its shipping container and store the packaging material in a safe location. 3. Position the transceiver with its handle on the right and slide it into the slot until it clicks into place. -
Page 76: Figure 27: Removing The Dust Cover From An Sfp Transceiver
Chapter 4: Cabling the Ports Note If you are ready to attach the fiber optic cable to the transceiver, continue with the next step. Otherwise, repeat steps 1 to 3 to install the remaining transceivers in the switch. 4. Remove the dust cover from the transceiver. Refer to Figure 27. Figure 27. -
Page 77: Figure 29: Connecting A Fiber Optic Cable To An Sfp Transceiver
IE200 Series Installation Guide Figure 29. Connecting a Fiber Optic Cable to an SFP Transceiver 7. Repeat this procedure to install and cable another transceiver. 8. Go to Chapter 5, “Powering On the Switch” on page 79. - Page 78 Chapter 4: Cabling the Ports...
-
Page 79: Chapter 5: Powering On The Switch
Chapter 5 Powering On the Switch This chapter contains the following procedures: “Connecting the Grounding Wire” on page 80 “Wiring the ALM IN and ALM OUT Connectors” on page 83 “Preparing the DC Power Cables” on page 88 ... -
Page 80: Connecting The Grounding Wire
Chapter 5: Powering On the Switch Connecting the Grounding Wire Here are the guidelines for the grounding wire: The wire should be minimum #16 AWG solid wire. The wire length should be as short as possible. Continuity from the grounding screw to the earth ground must be less than 0.05 ohms. -
Page 81: Figure 31: Loosening The Grounding Screw
IE200 Series Installation Guide Figure 31. Loosening the Grounding Screw 3. Wrap the grounding wire clockwise around the base of the grounding screw. Refer to Figure 32. Figure 32. Wrapping the Grounding Wire Around the Grounding Screw 4. Tighten the screw to secure the grounding wire to the switch. Refer to... -
Page 82: Figure 33: Securing The Grounding Wire To The Switch
Chapter 5: Powering On the Switch Figure 33. Securing the Grounding Wire to the Switch 5. Connect the other end of the ground wire to a ground point at the installation site. 6. Do one of the following: To wire the alarm connectors, go to “Wiring the ALM IN and ALM OUT Connectors”... -
Page 83: Wiring The Alm In And Alm Out Connectors
IE200 Series Installation Guide Wiring the ALM IN and ALM OUT Connectors For background information on the alarm connectors, refer to “Alarm In Connector” on page 36 and “Alarm Out Connector” on page 39. Here are general guidelines to the alarm connectors: ... -
Page 84: Figure 34: Polarity Legend For The Alarm Connectors
Chapter 5: Powering On the Switch and positive polarities of its two pins by examining the legends on the top panel. Refer to Figure 34. Figure 34. Polarity Legend for the Alarm Connectors The following procedure shows the ALM OUT connector. The procedure is the same for the ALM IN connector. -
Page 85: Figure 36: Wrapping The Wire Strands
IE200 Series Installation Guide Figure 36. Wrapping the Wire Strands Note Allied Telesis recommends that you also tin the wires with solder as added protection against loose strands. This guide does not provide instructions on how to tin wires. 3. Remove the alarm connector from the top panel. Figure 37 shows the removal of the ALM OUT connector. -
Page 86: Figure 38: Loosening The Wire Retaining Screws On An Alarm Connector
Figure 38. Loosening the Wire Retaining Screws on an Alarm Connector 5. Insert the wires into the connector and tighten the retaining screws to secure the wires. Refer to Figure 39. Allied Telesis recommends tightening the screws to 2 to 3 in.-lbs. Positive (+) Negative (-) Figure 39. -
Page 87: Figure 40: Inserting The Dc Connector Into The Alarm Connector
IE200 Series Installation Guide Warning Check to see if there are any exposed copper strands coming from the installed wires. When this installation is done correctly there should be no exposed copper wire strands extending from the terminal block. Any exposed wiring can conduct harmful levels of electricity to persons touching the wires. -
Page 88: Preparing The Dc Power Cables
Chapter 5: Powering On the Switch Preparing the DC Power Cables You can power the switch with either one or two DC power supplies. For power supply specifications, refer to “Power Supplies” on page 47. Power supplies are connected to the 4-wire, DC power connector on the top panel of the switch. -
Page 89: Figure 42: Stripping A Power Cable Wire
This step is to prevent loose strands from touching other wires and causing an electrical short. Note Allied Telesis recommends that you also tin the wires with solder as added protection against loose strands. This guide does not provide instructions on how to tin wires. -
Page 90: Figure 44: Loosening The Wire Retaining Screws On The Pwr 1 - Pwr 2 Cable Connector
Cable Connector 5. Insert the wires into the connector and tighten the retaining screws to secure the wires. Refer to Figure 45. Allied Telesis recommends tightening the screws to 2 to 3 in.-lbs. PWR 1 PWR 2 Figure 45. Inserting the Wires into the PWR 1 - PWR 2 Cable Connector 6. -
Page 91: Figure 46: Verifying The Wire Installation
IE200 Series Installation Guide Incorrect - Loose wire Correct Incorrect - Exposed wire. strands Figure 46. Verifying the Wire Installation Warning Check to see if there are any exposed copper strands coming from the installed wires. When this installation is done correctly there should be no exposed copper wire strands extending from the terminal block. -
Page 92: Powering On The Switch
Chapter 5: Powering On the Switch Powering On the Switch For power supply requirements, refer to “Power Supplies” on page 47. To power on the chassis, perform the following procedure: 1. Verify that the DC power supply is powered off. If there are two DC power supplies, verify that both units are powered off. -
Page 93: Verifying Switch Operations
IE200 Series Installation Guide 5. Wait a minimum of one minute for the switch to initialize its operating system. To monitor the console messages as the device initializes the management software, go to “Monitoring the Initialization Process” on page 94. -
Page 94: Monitoring The Initialization Process
Verifying release... OK Booting... Starting base/first... [ OK ] Mounting virtual filesystems... [ OK ] Allied Telesis Inc. AlliedWare Plus (TM) Current release filename: IE200 Built: Tue Mar 29 03:50:20 UTC 2016 Mounting static filesystems... [ OK ] Checking flash filesystem... -
Page 95: Figure 49: Initialization Messages (Continued)
IE200 Series Installation Guide Starting base/apteryx... [ OK ] starting base/appmond... [ OK ] Starting base/clockcheck... [ OK ] Starting hardware openhpi... [ OK ] Starting hardware/timeout... [ OK ] Starting base/inet... [ OK ] Starting base/modules... [ OK ] Received event modules.done... -
Page 96: Starting A Local Management Session
Chapter 5: Powering On the Switch Starting a Local Management Session This section contains the procedure for starting a local management session on the switch. It also explains how to verify the PoE power budget on the AT-IE200-6FP or AT-IE200-6GP Switch. Please review the following information before performing the procedure: ... - Page 97 IE200 Series Installation Guide Note The baud rate must be set to the default 9600 bps to configure the bootloader. 4. Press Enter. You are prompted for the name and password of the manager account. 5. Enter the user name and password. The default values are “manager”...
- Page 98 Chapter 5: Powering On the Switch If the power budget is 120W, no further installation steps are required. Refer to the Software Reference for the IE200 Series Switches for instructions on how to configure the features of the switch. If the power budget is less than 120W, either the power supply does not meet the specifications in “Power Supplies”...
-
Page 99: Installing The Optional Drip Guard
IE200 Series Installation Guide Installing the Optional Drip Guard To install the drip guard, perform the following procedure: 1. Slide the drip guard over the top of the switch. The front overhang on the drip guard should project over the front of the switch. Refer to Figure 50. -
Page 100: Figure 51: Securing The Drip Guard
Chapter 5: Powering On the Switch 2. Install the four Phillips-head screws included with the drip guard to secure it to the switch. Refer to Figure 51. Figure 51. Securing the Drip Guard... - Page 101 “PWR 1 and PWR 2 LEDs” on page 102 “Twisted Pair Ports” on page 103 “SFP Slots” on page 105 “Power Over Ethernet” on page 106 Note For further assistance, please contact Allied Telesis Technical Support at www.alliedtelesis.com/support.
-
Page 102: Chapter 6: Troubleshooting
Chapter 6: Troubleshooting PWR 1 and PWR 2 LEDs Problem: A DC power supply is connected to the switch but the corresponding PWR 1 or PWR 2 LED on the front panel is off. Solutions: The unit is not receiving power from the power supply or the power is outside the operating range for the switch. -
Page 103: Twisted Pair Ports
IE200 Series Installation Guide Twisted Pair Ports Problem: The switch is powered on and forwarding traffic, but all the port LEDs are off. Solutions: The port LEDs may have been turned off with the ECOFRIENDLY LED command in the AlliedWare Plus operating system. - Page 104 Chapter 6: Troubleshooting Negotiation is connected to a remote device that has a fixed speed of 10 or 100 Mbps and a fixed duplex mode of full duplex. If this is the cause of the problem, adjust the duplex mode of the port on the network device or switch so that both ports are using the same duplex mode.
-
Page 105: Sfp Slots
IE200 Series Installation Guide SFP Slots Problem: The LINK/ACT LED for an SFP transceiver is off. Solutions: The fiber optic port on the transceiver cannot establish a link to a network device. Try the following: Verify that the remote network device connected to the fiber optic port is operating properly. -
Page 106: Power Over Ethernet
Chapter 6: Troubleshooting Power Over Ethernet Problem: The AT-IE200-6FP or AT-IE200-6GP Switch is not providing power to a PoE or PoE+ device. Solutions: Try the following: Check that the device’s power requirements do not exceed those listed in Table 2 on page 28. The power requirements should be included in the device’s documentation or data sheet. -
Page 107: Appendix A: Technical Specifications
Appendix A Technical Specifications This appendix contains the following sections: “Physical Specifications” on page 108 “Environmental Specifications” on page 110 “Power Specifications” on page 112 “Certifications” on page 113 “RJ-45 Twisted Pair Port Pinouts” on page 114 ... -
Page 108: Physical Specifications
Appendix A: Technical Specifications Physical Specifications Dimensions Table 13 lists the dimensions of the products. Table 13. Product Dimensions AT-IE200-6FT (WxHxD) 5.5 x 15.9 x 13.4 cm AT-IE200-6GT (2.17 x 6.25 ix 5.28 in.) AT-IE200-6FP 9.5 x 15.9 x 13.4 cm AT-IE200-6GP (3.74 x 6.25 ix 5.28 in.) Weights... -
Page 109: Table 16: Minimum Cabinet Dimensions
IE200 Series Installation Guide Cabinet Dimensions Table 16 provides the minimum cabinet dimensions. Table 16. Minimum Cabinet Dimensions Minimum Cabinet Dimensions 50.8 x 50.8 x 30.5 cm (WxHxD) (20.0 x 20.0 x 12.0 in) -
Page 110: Environmental Specifications
Maximum Operating Altitude 3,000 m (9,843 ft) Maximum Nonoperating Altitude 4,000 m (13,100 ft) Table 18 lists the ingress protection values. Table 18. Ingress Protection IE200 Series Switch Without Drip IP30 Guard IE200 Series Switch With Drip IP31 Guard Table 19 lists the vibration, shock, and rough handling specifications for the AT-IE200-6FT and AT-IE200-6GT Switches. -
Page 111: Table 20: Vibration, Shock, And Rough Handling Specifications For The At-Ie200-6Fp And At-Ie200-6Gp Switches
Resonance occurs in the 18-22Hz range. Note If the switch is installed on a DIN rail, Allied Telesis recommends installing DIN rail end clamps on both sides of the device to prevent damage or network traffic loss from vibration or shock. -
Page 112: Power Specifications
Appendix A: Technical Specifications Power Specifications Table 21 lists the maximum power consumption values. Table 21. Maximum Power Consumptions AT-IE200-6FT 32 watts AT-IE200-6GT AT-IE200-6FP 155 watts (including PDs’ consumption and margin) AT-IE200-6GP 35 watts (excluding PDs’ consumption) Table 22 lists the input power specifications. Table 22. -
Page 113: Certifications
IE200 Series Installation Guide Certifications The regulatory approvals of the product are listed in Table 24. Table 24. Regulatory Approvals RFI Emissions FCC Part 15B Class A EN55032 Class A EN61000-3-2 EN61000-3-3 VCCI-CISPR32:2016 Class A ICES-003:Issue 6 RFI Immunity EN55024... -
Page 114: Rj-45 Twisted Pair Port Pinouts
Appendix A: Technical Specifications RJ-45 Twisted Pair Port Pinouts Figure 52 identifies pin 1 on an RJ-45 twisted pair port. Pin 1 Figure 52. RJ-45 Port Pin Layout (Front View) Table 25 lists the pin signals for a port operating at 10 or 100 Mbps. Table 25. - Page 115 IE200 Series Installation Guide Table 26. Pin Signals for RJ-45 Twisted Pair Ports at 1000 Mbps Pair 2 + Pair 3 + Pair 3 - Pair 2 - Pair 4 + Pair 4 -...
-
Page 116: Rj-45 Style Serial Console Port Pinouts
Appendix A: Technical Specifications RJ-45 Style Serial Console Port Pinouts Figure 53 identifies pin 1 on the RJ-45 connector on the Console port. Pin 1 Figure 53. Console Port Pin Layout (Front View) Table 27 lists the pin signals for the RJ-45 style serial Console port. Table 27. -
Page 117: Pwr 1 And Pwr 2 Dc Power Connectors
IE200 Series Installation Guide PWR 1 and PWR 2 DC Power Connectors Table 28 lists the pin signals for the PWR 1 and PWR 2 DC power connectors on the AT-IE200-6FT and AT-IE200-6GT Switch. Table 28. PWR 1 and PWR 2 DC Connector Pin Signals on the AT-IE200-... - Page 118 Appendix A: Technical Specifications...
Need help?
Do you have a question about the IE200 Series and is the answer not in the manual?
Questions and answers
