Page 1: Installation Guide
IA Series INDUSTRIAL ETHERNET SWITCHES AT-IA708C AT-IA810M Installation Guide 613-002440 Rev. A... - Page 2 Telesis, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis, Inc. has been...
- Page 3 Electrical Safety and Emissions Standards This section contains the following: “US Federal Communications Commission” “Industry Canada” “Electrical/Mechanical Approvals” on page 4 “Translated Safety Statements” on page 4 US Federal Communications Commission Radiated Energy Note This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules.
-
Page 4: Translated Safety Statements
In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Translated Safety Statements Important: The indicates that translations of the safety statement are available in the PDF document Translated Safety Statements posted on the Allied Telesis website at alliedtelesis.com/support. -
Page 5: Table Of Contents
Contents Preface ....................................3 Document Conventions ..............................4 Contacting Allied Telesis ..............................5 Chapter 1: Overview ................................7 Product Overview ................................8 AT-IA708C Switch ..............................8 AT-IA810M Switch ..............................8 10/100Base-TX Twisted Pair Ports ..........................11 Basic Features ...............................11 Speed ..................................11 Duplex Mode ................................11 Wiring Configuration...............................12 Maximum Distance..............................12 Cable Requirements ..............................13... - Page 6 Contents Power Specifications ..............................48 RJ-45 Twisted Pair Port Pinouts............................49 RJ-45 Style Serial Console Port Pinouts ........................50...
-
Page 7: Preface
Preface This guide contains the installation instructions for the IA Series Industrial Ethernet switches. The switch models included in this manual are: AT-IA708C AT-IA810M The preface contains the following sections: “Document Conventions” on page 4 “Contacting Allied Telesis” on page 5... -
Page 8: Document Conventions
Preface Document Conventions This document uses the following conventions: Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings inform you that performing or omitting a specific action may result in bodily injury. -
Page 9: Contacting Allied Telesis
IA Series Ehternet Switches Installation Guide Contacting Allied Telesis If you need assistance with this product, you may contact Allied Telesis technical support by going to the Support & Services section of the Allied Telesis web site at www.alliedtelesis.com/support. You can find links for the following services on this page: 24/7 Online Support —... - Page 10 Preface...
-
Page 11: Chapter 1: Overview
Chapter 1 Overview This chapter contains the following sections: “Product Overview” on page 8 “10/100Base-TX Twisted Pair Ports” on page 11 “LEDs” on page 14 “DC Power and Ground Connectors” on page 18 “Console Port” on page 19 ... -
Page 12: Product Overview
Chapter 1: Overview Product Overview The IA Series switches are industrial Fast Ethernet switches, which support wide operating and storage temperatures.The eco-friendly feature can save power consumption on each port when the port has not established a link. The AT-IA708C model is an unmanaged switch; the AT-IA810M model is a managed switch. - Page 13 IA Series Ehternet Switches Installation Guide See Figure 2 for the port layout of the AT-IA810M switch. DC Power Connector Console Port Fiber Ports Copper Ports Figure 2. AT-IA810M Switch Warning Power cord is used as a disconnection device. To de-energize equipment, disconnect the power cord.
- Page 14 Chapter 1: Overview Management Methods Here are the methods for managing the switches: Local management through the Console port Remote Telnet and Secure Shell management Remote HTTP and HTTPS web browser management SNMPv2c ...
-
Page 15: 10/100Base-Tx Twisted Pair Ports
IA Series Ehternet Switches Installation Guide 10/100Base-TX Twisted Pair Ports The IA series switch has 8 10/100Base-TX ports. Basic Features Here are the basic features of the 10/100 Mbps twisted pair ports: 10Base-T and 100Base-TX compliant IEEE 802.3u Auto-Negotiation compliant ... -
Page 16: Wiring Configuration
Chapter 1: Overview Note A switch port that is connected to a network device that does not support Auto-Negotiation and has a fixed duplex mode of full-duplex should not set its duplex mode with Auto-Negotiation. A duplex- mode mismatch in which a switch port and a network device operate at different duplex modes, may occur. -
Page 17: Cable Requirements
IA Series Ehternet Switches Installation Guide Cable The cable requirements of the ports are given in Table 1. Requirements Table 1. Twisted Pair Cable for the 10/100Base-TX Ports Cable Type 10Mbps 100Mbps Standard TIA/EIA 568-B-compliant Category 3 shielded or unshielded cabling with 100 ohm impedance and a frequency of 16 MHz. -
Page 18: Leds
Chapter 1: Overview LEDs Here are descriptions of the switch’s LEDs. AT-IA708C The AT-IA708C switch has power and port LEDs as shown in Figure 3. Model Power LED Link/Activity LED Link/Activity LED Duplex Mode LED Duplex Mode LED Figure 3. AT-IA708C LEDs The LEDs on the AT-IA708C switch are described in Table 2. -
Page 19: At-Ia810M Model
IA Series Ehternet Switches Installation Guide Table 2. The AT-IA708C LEDs (Continued) State Description The port has not established a link, or the (Link/Activity) eco-friendly feature is on. Solid green The port has established a link at 100Mbps speed. Flashing... - Page 20 Chapter 1: Overview The LEDs on the AT-IA810M switch are described in Table 3. Table 3. The AT-IA810M LEDs State Description The switch is not receiving power. (Power) Solid green Power is on. The switch is operating normally or powered is off. Solid Red A system error occurred.
- Page 21 IA Series Ehternet Switches Installation Guide Table 3. The AT-IA810M LEDs (Continued) State Description The port has not established a link, (Link/Activity) for or the eco-friendly feature is on. the fiber ports Solid green The port has established a link.
-
Page 22: Dc Power And Ground Connectors
Chapter 1: Overview DC Power and Ground Connectors The IA series switch is equipped with the DC power connectors. The ground wire connector is located next to the DC power connectors. The DC power connectors are for DC power supplies. For cabling DC power cables, see “Wiring and Powering on the Switch”... -
Page 23: Console Port
IA Series Ehternet Switches Installation Guide Console Port The AT-IA810M switch has a console port to configure the features and parameter settings of the switch. This type of management uses serial RS- 232 and is commonly referred to as local or out-of-band management because it is not conducted over your network. -
Page 24: Reset Button
Chapter 1: Overview Reset Button The AT-IA810M switch has a reset button to reset the switch. The switch reinitializes its operating system. You may reset the switch when experiencing a problem. The reset button is recessed in the chassis. To press it, uses a straightened paper clip or similar object. -
Page 25: Chapter 2: Installing The Switch
Chapter 2 Installing the Switch This chapter contains the following procedures: “Reviewing Safety Precautions” on page 22 “Choosing a Site for the Switch” on page 25 “Unpacking the Switch” on page 26 “Installing the Switch on a Table or Desktop” on page 27 ... -
Page 26: Reviewing Safety Precautions
Note The indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” posted on the Allied Telesis website at www.alliedtelesis.com. Warning Class 1 Laser product. L1 Warning Do not stare into the laser beam. L2... - Page 27 IA Series Ehternet Switches Installation Guide Warning Class I Equipment. This equipment must be earthed. The power plug must be connected to a properly wired earth ground socket outlet. An improperly wired socket outlet could place hazardous voltages on accessible metal parts. E4...
- Page 28 Chapter 2: Installing the Switch Note If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than the room ambient temperature. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (Tmra).
-
Page 29: Choosing A Site For The Switch
IA Series Ehternet Switches Installation Guide Choosing a Site for the Switch Observe these requirements when planning the installation of the switch. If you plan to install the switch in an equipment rack, the rack should be safely secured so that it will not tip over. Devices in a rack should be installed starting at the bottom, with the heavier devices near the bottom of the rack. -
Page 30: Unpacking The Switch
Table 4. Components in the Bracket Kit One 3-pin terminal block for DC power and ground wire Four rubber feet Console cable (for the AT-IA810M model only) 4. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. -
Page 31: Installing The Switch On A Table Or Desktop
IA Series Ehternet Switches Installation Guide Installing the Switch on a Table or Desktop You may install the switch on a table or desktop. To install the switch on a table or desktop, perform the following procedure: 1. Remove all the items from the packing. -
Page 32: Installing The Switch On A Din Rail
Chapter 2: Installing the Switch Installing the Switch on a DIN Rail The series switch comes with a DIN rail bracket pre-installed on the back panel. The bracket is compatible with DIN 35x7.5mm rails. Here is the procedure for installing the switch on a DIN rail: 1. -
Page 33: Chapter 3: Powering On The Switch
Chapter 3 Powering On the Switch This chapter contains the following procedures: “Wiring and Powering on the Switch” on page 30 ... -
Page 34: Wiring And Powering On The Switch
Chapter 3: Powering On the Switch Wiring and Powering on the Switch To wire and power on the IA series switch, perform the following procedure: Warning As a safety precaution, install a circuit breaker with a minimum value of 15 Amps between the equipment and the DC power source. - Page 35 IA Series Ehternet Switches Installation Guide Warning For centralized DC power connection, install only in a restricted access area. Note A tray cable is required to connect the power source if the unit is powered by centralized DC power. The tray cable must be a UL listed Type TC tray cable and rated at 600 V and 90 degrees C, with three conductors, minimum 14 AWG.
- Page 36 Allied Telesis recommends that you use at least four cable ties 10 centimeters (4 inches) apart with the first one located within 15 centimeters (6 inches) of the terminal block.
- Page 37 IA Series Ehternet Switches Installation Guide 10. Power on the circuit breaker. 11. Verify that the Power LED is green. If it is not, refer to Chapter 6, “Troubleshooting” on page 45.
- Page 38 Chapter 3: Powering On the Switch...
-
Page 39: Chapter 4: Cabling The Networking Ports
Chapter 4 Cabling the Networking Ports This chapter contains the following procedures: “Cabling the Twisted Pair Ports” on page 36 ... -
Page 40: Cabling The Twisted Pair Ports
Chapter 4: Cabling the Networking Ports Cabling the Twisted Pair Ports This section contains the guidelines to cabling the twisted pair and fiber optic ports. Twisted Pair Here are the guidelines to cabling the 10/100Base-TX twisted pair ports: Ports The cable specifications are listed in Table 1 on page 13. ... - Page 41 IA Series Ehternet Switches Installation Guide appropriate for ports connected to network devices that do not support Auto-Negotiation and have a fixed duplex mode. You should disable Auto-Negotiation on those ports and set their duplex modes manually to avoid the possibility of duplex mode mismatches.
- Page 42 Chapter 4: Cabling the Networking Ports...
-
Page 43: Chapter 5: Starting A Management Session
Chapter 5 Starting a Management Session This chapter contains the following procedures: “Starting the Initial Management Session” on page 40 “Starting a Management Session using the Web Interface” on page 43 Note This chapter only applies to the AT-IA810M switch. -
Page 44: Starting The Initial Management Session
Chapter 5: Starting a Management Session Starting the Initial Management Session The AT-IA810M switch provides two management interfaces: the Web interface and Command Line Interface (CLI); however, the initial management session of the switch must be through the CLI. Note This section only applies to the AT-IA810M switch. -
Page 45: Assigning An Ipv4 Address To The Switch
IA Series Ehternet Switches Installation Guide Note The switch comes with one manager account with a user name of “manager” and the default password of “friend” for you to log in. 6. Type the user name and press Enter. login: manager password: You are prompted to type the password. -
Page 46: Enabling Http Server
Chapter 5: Starting a Management Session DHCP Client.....Disabled Directed broadcast..No ----------------------------------------------- Enabling HTTP To enable HTTP Server, perform the following procedure: Server 1. Log in to the switch as shown in “Starting the Initial Management Session” on page 40. 2. Enable HTTP Server. Manager sales>... -
Page 47: Starting A Management Session Using The Web Interface
3. Enter the IP address of your switch into the Internet Explorer. 4. Enter the user name and password. Figure 11. IA series switch Login Screen 5. Press OK. You are logged in and the Web interface appears. See Figure 12 on... - Page 48 Chapter 5: Starting a Management Session Figure 12. The AT-IA810M Switch Web Interface...
-
Page 49: Chapter 6: Troubleshooting
This chapter contains suggestions on how to troubleshoot the switch if a problem occurs. Note For further assistance, please contact Allied Telesis Technical Support at www.alliedtelesis.com/support. Problem 1: All the LEDs on the switch are off. Solutions: Try the following: Try connecting the unit to another power source. - Page 50 Chapter 6: Troubleshooting Problem 3: Network performance between a twisted pair port on the switch and a network device is slow. Solution: There might be a duplex mode mismatch between the port and the network device. This occurs when a twisted pair port using Auto- Negotiation is connected to a device with a fixed duplex mode of full duplex.
-
Page 51: Appendix A: Technical Specifications
Appendix A Technical Specifications This section contains the following product technical specifications: ”Physical Specifications” on page 47 ”Environmental Specifications” on page 48 ”Power Specifications” on page 48 ”RJ-45 Twisted Pair Port Pinouts” on page 49 ”RJ-45 Style Serial Console Port Pinouts” on page 50 ... -
Page 52: Environmental Specifications
Appendix A: Technical Specifications Environmental Specifications The AT-IA708C Switch Table 8. Environmental Specifications for the AT-IA8708C Switch Description Specification Operating Temperature -10° C to 70° C (14° F to 158° F) Storage Temperature -20° C to 70° C (-4° F to 158° F) Operating Humidity Less than 80% non-condensing Storage Humidity... - Page 53 IA Series Ehternet Switches Installation Guide Input Voltages Table 11. Input Voltages Model Input Voltage AT-IA708C 24 VDC AT-IA810M 12-24 VDC RJ-45 Twisted Pair Port Pinouts Figure 13 illustrates the pin layout of the RJ-45 connectors and ports. Figure 13. RJ-45 Socket Pin Layout (Front View) Table 12 lists the pin signals for 10 and 100 Mbps.
- Page 54 Appendix A: Technical Specifications RJ-45 Style Serial Console Port Pinouts Table 13 lists the pin signals of the RJ-45 style serial Console port. Table 13. RJ-45 Pin Signals Signal Request to send Not used Transmit Data Ground Ground Receive Data Not used Clear to send...
