Page 1: Installation Guide
IE210L Series Industrial Gigabit Ethernet Switches AT-IE210L-10GP AT-IE210L-18GP Installation Guide 613-002594 Rev. A... - Page 2 Telesis Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis Inc. has been...
-
Page 3: Electrical Safety And Emissions Standards
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Electrical Safety and Emissions Standards This product meets the following standards:. U.S. Federal Communications Commission Radiated Energy Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. -
Page 4: Translated Safety Statements
Translated Safety Statements Important: The indicates that a translation of the safety statement is available in a PDF document titled Translated Safety Statements on the Allied Telesis Inc. website at www.alliedtelesis.com/support. -
Page 5: Table Of Contents
Power Supply ............................. 30 Fans ................................31 Chapter 2: Installation ........................... 33 Safety Precautions ............................. 34 Site Selection IE210L Series Switch Installation..................36 Unpack AT-IE210L-10GP Switch:......................37 Unpack AT-IE210L-18GP Switch....................... 38 Table or Desktop Switch Installation ......................39 Remove Rubber Feet From Switch Chassis ....................40 Install AT-IE210L-10GP Switch in Equipment Rack .................. - Page 6 Contents Appendix A: Technical Specifications ......................63 Physical Specifications ..........................63 Dimensions ............................63 Weight ..............................63 Environmental Specifications ........................64 Power Specifications ..........................64 Electrical safety and electromagnetic certifications ..................65 Cable Requirements........................... 66 Connectors and port pinouts ........................67...
- Page 7 Figure 2: AT-IE210L-10GP Back Panel......................16 Figure 3: AT-IE210L-18GP Front Panel ......................17 Figure 4: AT-IE210L-18GP Back Panel......................17 Figure 5: IE210L Series System LEDs ......................26 Figure 6: Twisted Pair Port L/A and PoE LEDs ....................28 Figure 7: SFP Link/Activity LEDs........................29 Figure 8: AT-IE210L-10GP Shipping Package Contents ................
- Page 9 Tables Table 1. IEEE powered device classes ......................23 Table 2. System LED Functional Descriptions ....................27 Table 3. Link/Activity/Speed and PoE LED descriptions ................28 Table 4. SFP Link/Activity LED functional descriptions .................. 29 Table 5. Chassis dimensions .......................... 63 Table 6.
-
Page 11: Preface
Preface This guide contains the installation instructions for the AT-IE210L-10GP and AT-IE210L-18GP Gigabit Ethernet Switches. This preface contains the following sections: “Symbol Conventions” on page 12 “Contacting Allied Telesis” on page 13 ... -
Page 12: Symbol Conventions
Preface Symbol Conventions This document uses the following conventions: Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings inform you that performing or omitting a specific action may result in bodily injury. -
Page 13: Contacting Allied Telesis
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Contacting Allied Telesis If you need assistance with this product, you may contact Allied Telesis technical support by going to the Support & Services section of the Allied Telesis web site at www.alliedtelesis.com/support. You can find links for... - Page 14 Preface...
-
Page 15: Chapter 1: Overview
Chapter 1 Overview This chapter provides descriptions of the AT-IE210L-10GP and AT-IE210L-18GP Industrial Gigabit Ethernet Switches and contains the following sections: “AT-IE210L-10GP Switch Front and Back Panels” on page 16 “AT-IE210L-18GP Switch Front and Back Panels” on page 17 ... -
Page 16: At-Ie210L-10Gp Switch Front And Back Panels
Chapter 1: Overview AT-IE210L-10GP Switch Front and Back Panels Figure 1 illustrates the front panel of the AT-IE210L-10GP Gigabit Ethernet Switch. Console System 10/100/1000Base-T Port LEDs Slots Slots Twisted Pair Ports Slot Figure 1. AT-IE210L-10GP Front Panel Figure 2 illustrates the back panel of the AT-IE210L-10GP Gigabit Ethernet Switch. -
Page 17: At-Ie210L-18Gp Switch Front And Back Panels
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide AT-IE210L-18GP Switch Front and Back Panels Figure 3 illustrates the front panel of the AT-IE210L-18GP Gigabit Ethernet Switch. System LEDs Slot 10/100/1000Base-T Console Port Slots Twisted Pair Ports Figure 3. AT-IE210L-18GP Front Panel Figure 4 illustrates the back panel of the AT-IE210L-18GP Gigabit Ethernet Figure 4. -
Page 18: Ie-210L Series Switch Features
Chapter 1: Overview IE-210L Series Switch Features This section describes the hardware features of the IE210L Series Industrial Gigabit Ethernet Switches. Twisted Pair Here are the basic features of the 10/100/1000Mbps twisted-pair ports: Ports AT-IE210L-10GP, or AT-IE210L-18GP switches: 8 or 16 PoE ports ... -
Page 19: Leds
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide LEDs Here is a brief description of the port LEDs: SD card, FAULT and POWER LEDs. Refer to “System LEDs” on page 26. Link/Activity/Speed/PoE LEDs for the PoE twisted pair ports. Refer ... -
Page 20: Management Software
User Interface) for in-band, over-the-network management. For configuration and command details refer to the product documentation on the Support tab of the product series web page, at Allied Telesis alliedtelesis.com/products/IE210-series. These documents are available from the above links on our website at Allied Telesis alliedtelesis.com. -
Page 21: Twisted Pair Ports
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Twisted Pair Ports The number of twisted pair ports supported by each IE210L Series switch 8 ports: AT-IE210L-10GP 16 ports: AT-IE210L-18GP All ports are 10BASE-T, 100BASE-TX, and 1000BASE-T compliant. You can set the port speeds and duplex modes either automatically with IEEE 802.3u Auto-Negotiation or manually with the management software. -
Page 22: Power Over Ethernet (Poe)
A device that provides PoE to other network devices is referred to as power sourcing equipment (PSE). The IE210L Series switches act as PSE units by adding DC power to the network cable, thus functioning as a central power source for other network devices. -
Page 23: Powered Device Classes
Powered devices are grouped into the five classes listed in Table 1 on page 23. The classes are based on the amount of power the devices Classes require. The IE210L Series PoE switches support all five classes. Table 1. IEEE powered device classes Maximum power output... -
Page 24: Port Prioritization
Chapter 1: Overview Port If the power requirements of the powered devices exceed the switch’s power budget, the switch denies power to some ports based on a system Prioritization called port prioritization. You may use this mechanism to ensure that powered devices critical to the operations of your network are given preferential treatment by the switch in the distribution of power should the demands of the devices exceed the available capacity. - Page 25 100BASE-TX devices that carry the network data. With mode B, the power is provided over the spare wires. The ports on IE210L Series PoE switches deliver the power using pins 1, 2, 3, and 6, which corresponds to mode A in the IEEE 802.3af standard.
-
Page 26: Leds
Chapter 1: Overview LEDs This section describes the four types of LEDs on IE210L Series switches: ”System LEDs” “Twisted Pair Port LEDs” on page 28 “SFP LEDs” on page 29 System LEDs The IE Series switch System LEDs report: The status of the SD card. -
Page 27: Table 2. System Led Functional Descriptions
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Table 2 describes the system LEDs (SD card, system FAULT, and system POWER) for IE210L Series switches. Table 2. System LED Functional Descriptions Description State SD card is not inserted OR the ecofriendly feature... -
Page 28: Twisted Pair Port Leds
Chapter 1: Overview Twisted Pair Port The IE210L Series switches indicate Link/Activity/Speed and PoE status with two LEDs for each twisted pair port (Figure 6). For each port: LEDs The left L/A LED corresponds to Link/Activity/Speed. The right PoE LED corresponds to PoE status. -
Page 29: Sfp Leds
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide SFP LEDs The IE210L Series switches have SFP Link/Activity (L/A) LEDs on the front panel. See Figure 7. The SFP L/A LEDs indicate the activity status for each SFP slot. Each SFP... -
Page 30: Power Supply
Chapter 1: Overview Power Supply Each switch has an internal power supply with a single AC power supply socket on the back panel. To power the switch on or off, connect or disconnect the power cord provided with the switch. Four power cords and a power cord retainer hook are supplied with the switch. -
Page 31: Fans
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Fans The switches have internal fans as follows: AT-IE210L-10GP - one fan AT-IE210L-18GP - two fans You cannot remove or replace these fans in the field. The fan status is indicated with the FAULT LED. - Page 32 Chapter 1: Overview...
-
Page 33: Chapter 2: Installation
Chapter 2 Installation This chapter contains the following sections: “Safety Precautions” on page 34 “Site Selection IE210L Series Switch Installation” on page 36 “Unpack AT-IE210L-10GP Switch:” on page 37 “Unpack AT-IE210L-18GP Switch” on page 38 “Table or Desktop Switch Installation” on page 39 ... -
Page 34: Safety Precautions
Chapter 2: Installation Safety Precautions Please review the following safety precautions before you begin to install the chassis or any of its components. Note The indicates that a translation of the safety statement is available in a PDF document titled Translated Safety Statements. Warning To prevent electric shock, do not remove the cover. - Page 35 IE210L Series Industrial Gigabit Ethernet Switch Installation Guide All countries: Install product in accordance with local and National Electrical Codes. E8 Circuit overloading: Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of circuits might have on overcurrent protection and supply wiring.
-
Page 36: Site Selection Ie210L Series Switch Installation
Chapter 2: Installation Site Selection IE210L Series Switch Installation You can install an IE210L Series switch on a desktop, in a standard 19-inch equipment rack, or on a wall. Observe the following requirements when choosing a site for your switch: If you plan to install the switch in an equipment rack, verify that the ... -
Page 37: Unpack At-Ie210L-10Gp Switch
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Unpack AT-IE210L-10GP Switch: To unpack the AT-IE210L-10GP switch, perform the following procedure: 1. Remove all of the components from the shipping package. Note Store the packaging material in a safe location. You must use the original shipping material if you need to return the unit to Allied Telesis. -
Page 38: Unpack At-Ie210L-18Gp Switch
Chapter 2: Installation Unpack AT-IE210L-18GP Switch To unpack the AT-IE210L-18GPswitch, perform the following procedure: 1. Remove all of the components from the shipping package. Note Store the packaging material in a safe location. You must use the original shipping material if you need to return the unit to . 2. -
Page 39: Figure 10: Attach Rubber Feet To Switch
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Table or Desktop Switch Installation Here are the guidelines to selecting a suitable site for table or desktop use: The table should be level and stable and the power outlets should ... -
Page 40: Remove Rubber Feet From Switch Chassis
Chapter 2: Installation Remove Rubber Feet From Switch Chassis If rubber feet are installed on the bottom the chassis, they must be removed before you install the switch in a 19-inch equipment rack or on a wall. To do this, follow these steps: 1. -
Page 41: Install At-Ie210L-10Gp Switch In Equipment Rack
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Install AT-IE210L-10GP Switch in Equipment Rack These instructions show you how to install an AT-IE210L-10GP switch in an equipment rack with parts from the AT-RKMT-J14 Rack Mount Kit. This kit is not supplied with the switch, however, it can be purchased separately from your Allied Telesis dealer. -
Page 42: Figure 13: Mount At-Ie210L-10Gp Switch In Equipment Rack
Chapter 2: Installation 2. Mount the AT-IE210L-10GP switch in a 19-inch equipment rack using four equipment rack screws (not supplied). Refer to Figure 13. Figure 13. Mount AT-IE210L-10GP Switch in Equipment Rack 3. Go to “Switch Cable Installation” on page 45. -
Page 43: Install At-Ie210L-18Gp Switch In Equipment Rack
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Install AT-IE210L-18GP Switch in Equipment Rack These instructions show you how to install an AT-IE210L-18GP switch in an equipment rack with parts from the AT-RKMT-J13 Rack Mount Kit. This kit is not supplied with the switch, however, it can be purchased separately from your Allied Telesis dealer. -
Page 44: Figure 15: Mount At-Ie210L-18Gp Switch In Equipment Rack
Chapter 2: Installation 2. Mount the switch in a 19-inch equipment rack using four equipment rack screws (supplied with the equipment rack) (Figure 15). Figure 15. Mount AT-IE210L-18GP Switch in Equipment Rack 3. Go to “Switch Cable Installation” on page 45. -
Page 45: Switch Cable Installation
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Switch Cable Installation Observe the following guidelines when connecting twisted pair and fiber optic cables to the ports on the switch: Select the recommended cable for the twisted pair ports by ... - Page 46 Chapter 2: Installation setting is appropriate for ports connected to network devices that also support Auto-Negotiation. The default speed setting of Auto-Negotiation is not appropriate for ports connected to 10BASE-T and 100BASE-TX network devices that do not support Auto-Negotiation and have fixed speeds. For those switch ports, you should disable Auto-Negotiation and set the port’s speed manually to match the speeds of the network devices.
-
Page 47: Power On The Switch
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Power ON the Switch To power on the IE210L Series switch, perform the following procedure: 1. Lift the power cable hook on the AC power plug located on the back of the switch. Refer to Figure 16. - Page 48 Chapter 2: Installation 3. Plug the other end of the power cord into a wall outlet. Warning Power cord is used as a disconnection device. To de-energize equipment, disconnect the power cord. E3 Pluggable Equipment: The socket outlet shall be installed near the equipment and shall be easily accessible.
-
Page 49: Management Software
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Management Software The switches are shipped with the management software pre-installed. The software provides a command line interface and a GUI (Graphical User Interface) for in-band, over-the-network management. For configuration and command details refer to the product documentation on the Support tab of the product series web page, at alliedtelesis.com/... -
Page 50: Start A Local Management Session
This procedure requires a terminal or a terminal emulator program and the management cable that comes with the switch. To start a local management session on the IE210L Series switch, perform the following procedure: 1. Connect the RJ45 connector on the management cable to the console port on the front panel of the switch. -
Page 51: Monitor Initialization Processes
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Monitor Initialization Processes It takes about thirty seconds for the switch to initialize its management software programs and features, and load the default configuration. You may also monitor the bootup sequence by connecting a terminal or computer that has a terminal emulator program, to the console port on the master switch. -
Page 52: Figure 20: Switch Initialization Messages (Continued)
Chapter 2: Installation Starting base/portmapper... Received event syslog.done Starting base/reboot-stability... Checking system reboot stability... Starting base/cron... Starting base/appmond... Starting hardware/openhpi... Starting hardware/timeout... Starting base/inet... Starting base/modules... Received event modules.done Received event board.inserted Starting network/poefw... Received event poefw.done Received event hardware.done Starting network/startup... - Page 53 IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Received event network.configured awplus login:...
-
Page 54: Install Sfp Transceivers
SFP transceivers are hot-swappable. You may install them while the chassis is powered on. Your Allied Telesis sales representative can provide you with a list of supported transceivers for the units. The operational specifications and fiber optic cable requirements ... -
Page 55: Sfp Installation
3. If you are installing the transceiver in Port 9 (the top slot), position the transceiver with the Allied Telesis label facing up. If you are installing the transceiver in Port 10 (the bottom slot), position the transceiver with the label facing down. -
Page 56: Figure 23: Remove Sfp Transceiver Dust Cover
Chapter 2: Installation 5. Remove the dust cover from the SFP transceiver. Refer to Figure 23 Figure 23. Remove SFP Transceiver Dust Cover 6. Verify that the SFP handle is in the locked position. If the transceiver is in a top slot, the handle should be in the upright position. Refer to Figure 24. -
Page 57: Remove Sfp Transceiver
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Remove SFP Transceiver To remove a SFP transceiver from the IE210L chassis, perform the following procedure: 1. Remove the cable installed in the SFP transceiver. 2. Insert the SFP transceiver dust cover into the SFP transceiver. Refer to Figure 25. -
Page 58: Figure 27: Remove Sfp Module From Sfp Slot
Chapter 2: Installation 4. With the SFP transceiver handle in the unlock position, gently remove the module. Refer to Figure 27. Figure 27. Remove SFP Module from SFP Slot 5. Install the dust plug for the SFP slot. Refer to Figure 28. Figure 28. -
Page 59: Chapter 3: Troubleshooting
This chapter contains information on how to troubleshoot the switch if a problem occurs. Note For further assistance, please contact Allied Telesis Technical Support at www.alliedtelesis.com/support. Problem 1: The POWER LED on the front of the switch is off. Solutions: The unit is not receiving power. Try the following: Verify that the power cord is securely connected to the power ... - Page 60 Chapter 3: Troubleshooting Note A 1000BASE connection may require five to ten seconds to establish a link. Problem 3: The Link/Activity/Speed LED for an SFP transceiver is off. Solutions: The fiber optic port on the transceiver is unable to establish a link to a network device.
- Page 61 IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Verify that the location of the switch allows for adequate airflow. The unit will shut down if it is in danger of overheating. Problem 5: A port on the AT-IE210L-10GP or AT-IE210L-18GP switch is not providing power to a PoE device.
- Page 62 Chapter 3: Troubleshooting original cable or the network device. If the problem is with an SFP transceiver, check that the transceiver is fully inserted in the slot.
-
Page 63: Appendix A: Technical Specifications
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Appendix A Technical Specifications This appendix describes the technical specifications of the IE210L Series switches. The following specifications are included: “Physical Specifications” “Environmental Specifications” on page 64 “Power Specifications” on page 64 ... -
Page 64: Environmental Specifications
Appendix A: Technical Specifications Environmental Specifications Table 7. Environmental Specifications Operating Temperature 0° C to +65° C (32° F to 149° F) Storage Temperature -30° C to 70° C (-22° F to 158° F) Operating Humidity 5% to 90% RH non-condensing Storage Humidity 5% to 95% RH non-condensing Operating Altitude Range... -
Page 65: Electrical Safety And Electromagnetic Certifications
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Electrical safety and electromagnetic certifications Table 10. Safety and electromagnetic emissions certifications EN 55032 Class A EN 55024 EN 61000-3-2 EN 61000-3-3 EN 62311 FCC Part 15 (CFR 47) Class A VCCI Class A... -
Page 66: Cable Requirements
Appendix A: Technical Specifications Cable Requirements Cable requirements for the 10BASE-T/100BASE-TX/1000BASE-T ports operating at 10, 100, or 1000 Mbps are in Table 11. Table 11. Twisted Pair Cable Requirements At 10 or 100Mbps 10Mbps 100Mbps 1000Mbps Cable type Cat 3: Standard TIA/EIA 568- B-compliant Category 3 shielded or unshielded cabling with 100 ohm impedance and... -
Page 67: Connectors And Port Pinouts
IE210L Series Industrial Gigabit Ethernet Switch Installation Guide Connectors and port pinouts This section lists the connectors and connector pinouts. Figure 29 illustrates the pin layout for an RJ45 connector and port. Figure 29. RJ45 connector and port pin layout Table 12 lists the RJ45 pin signals when a twisted pair port is operating in the MDI configuration. -
Page 68: Table 14. Rj-45 1000Base-T Connector Pinouts
Appendix A: Technical Specifications Table 14 lists the RJ45 connector pins and their signals when a 1000BASE-T port is operating at 1000Mbps. Table 14. RJ-45 1000BASE-T connector pinouts Pair Signal TX and RX+ TX and RX- TX and RX+ TX and RX+ TX and RX- TX and RX- TX and RX+...
