Remote Control
A. Fix the 18650x2 Battery Holder and Adeept Remote Control Shield.
Assemble the following components
M3*10 Countersunk
Head Screw
18650x2
Battery Holder
x1
Adeept Remote
Control Shield
x1
Effect diagram after assembling
x2
M3 Nut x2
www.adeept.com
The wiring on the 18650x2
Battery Holder shall not be
pressed between the
18650x2 Battery Holder and
the Adeept Remote Control
Shield, so as to avoid short
circuit caused by metal
puncturing on the Adeept
Remote Control Shield.
