System Layout

Mailing System with Auto-feeder
Auto-Feeder
Auto Label Dispenser
System Base
Weighing Platform
Control Panel
Hopper
Rear Guide-Wall
Side Guide
Jam Release Handle
Automatically feeds the system with envelopes
(optional).
Contains labels to be printed.
Prints envelopes (or labels) and controls the Mailing
System.
Measures the weight of mail pieces.
Allows you to control the Mailing System.
Beginning of mail transport path.
Guides envelopes into the feeder.
Holds large envelopes in place for feeding.
Allows you to remove jammed envelopes or labels.
