quadient iX-5 Series Quick Installation Manual

iX-5 Series
Quick Installation Guide
Machine components:
Automatic
k
feeder cable
Automatic
feeder
1 1
Unpack all components from the box, remove packaging
and any transit tape.
5
Lift mailing system slightly on the left hand side and align the hooks to attach the automatic
feeder (b) – attach the catch tray (c) to the right hand side of the mailing system.
9
Installation Process
1 LAN
OK
Select LAN and press to test connection type.
Mailing system
base
Catch tray
Back of the machine
2
Lift the cover of the mailing system to
reveal the ink cartridge (i) and meter
bays.
6
Attach the weighing platform
shelf (if applicable)
10
Installation Process
Enter your registration code
l
l
OK
Mem
Enter your registration code.
Shelf
Weighing platform
3
Place the meter (j) into the meter bay and slide in until it fits securely
(j) into position.
7
(e) and Connect the weighing platform connector
cable (k) at the back of the mailing system. Then connect the LAN
(d).
cable (g) and power cable
11
Installation Process
Press the 'Next' to start the
Online service
declaration.
Next
Follow the steps on screen to complete the
procedure.
LAN cable Power cable
Weighing platform
cable
4
Insert the ink cartridge (i) at an angle into the machine with the 'TOP'
and 'LOCK' stickers facing upwards. Push the ink cartridge
back of the mailing system until you hear a 'click' - close the cover of the
mailing system.
8
k
(f) and automatic feeder Turn on the mailing system using the switch
behind the power cable
(h) to either side of the mailing system.
on screen.
For more help with your installation, please visit
kb.quadient.ca/ix5_install_en
Ink cartridge Meter
(i) towards the
(h) and follow the steps
