quadient iX-5 Series Quick Installation Manual

iX-5 Series Base
Quick Installation Guide
Machine components:
Machine Base
Feeding Table
1
Unpack all components from the box, remove packaging
and any transit tape.
5
Lift machine slightly on the left hand side and align the hooks to attach the feeding table
attach the catch tray (c) to the right hand side of the machine.
9
Installation Process
1 LAN
OK
Select LAN and press to test connection type.
For more help with your installation, please visit:
Catch Tray
Back of the machine
2
Lift the cover of the machine to reveal the
ink cartridge (i) and meter (j) locations.
6
(b) – Attach the weighing platform
shelf (if applicable)
10
Installation Process
Press the 'Next' to start the
Online service
declaration.
Next
Follow the steps on screen to complete the
procedure
Shelf
Weighing Platform
3
Place the meter (j) into the meter bay and slide in until it fits securely
into position.
7
(e) and Connect the weighing platform connector
(d). at the back of the machine. Then connect the LAN cable
power cable (h) to either side of the machine.
11
Your mailing system is now
Login
ready to use. Your default
user pin is 1234.
Enter PIN code Please call the Neopost
service team on 016250900
1234
to retrieve your pin for
OK adding credit and then follow
the instructions on the quick
start guide.
kb.quadient.ie/ix5_install
LAN Cable Power Cable
Weighing Platform
Cable
4
Insert the ink cartridge (i) at an angle into the machine with the 'TOP'
and 'LOCK' stickers facing upwards. Push the ink cartridge
the back of the machine until you hear a 'click' - close the cover of the
machine.
8
(f) into a COM PORT Turn on the machine using the switch behind the
(g) and power cable
For more information or if you experience any
issues, please visit :
Ink Meter
Cartridge
(i) towards
(h) and follow the steps on screen.
kb.quadient.ie/ix5
