quadient iX-3 Series Product Replacement Manual

iX-3 Series Base
Product Replacement Guide
Machine components:
Feeding Table
N1. Remove the components from your original machine
1
Remove the feeding table (b) from the franking machine base.
5 6
Turn off the machine by pressing the
Remove LAN cable (f), weighing platform cable
power button.
cable (g).
Average Time Required: 15 minutes
Machine Base
Weighing Platform
Catch Tray
2
Lift the cover of the machine to reveal the ink
cartridge (h) and meter (i) bays.
(e) and power
LAN Cable
Weighing Platform
Cable
3
When opening the cover, the ink cartridge
to the replacement position. Press down on the back
of the ink cartridge to disengage it. Lift out the ink
cartridge.
N2. Unpack your replacement
1
7 1
Remove the weighing platform Remove replacement unit from box & place original unit back into
box ready for collection.
(d) from the machine.
Power Cable Ink
Cartridge
4
(h) moves Open the meter bay latch, pull forward the meter
and remove it.
2
Lift the cover of the machine to reveal the
ink cartridge
Continue
Meter
(i)
(h) and meter (i) bays.
