11. CONFIGURATION OF THE BATTERY PACK(S)

The minimum number of the battery bank:
According to the requirements of the batteries' specifications, please refer to the following to
choose proper battery groups (each group or each string consists of 10 pieces of 12V battery in
series) for the Battery Pack(s) in order to maintain longer service life of the batteries and to safely
use the batteries for the UPS system as well.
The configuration table of the number of the battery packs:
(the part with no color in the table indicates that the configuration is not allowed )
1. Configuration of 12V24Ah battery
Power
1 string
4kVA
8kVA
12kVA
16kVA
20kVA
24kVA
2.Configuration of 12V38Ah battery
Power
1 string
4kVA
8kVA
12kVA
16kVA
20kVA
24kVA
3. Configuration of 12V65Ah battery
Power
1 string
4kVA
8kVA
12kVA
16kVA
20kVA
24kVA
2 strings
3 strings
2 strings
3 strings
2 strings
3 strings
30
4 strings
5 strings
4 strings
5 strings
4 strings
5 strings
6 strings
6 strings
6 strings
